Peplink BPL-5000-EC-100G-PRM 100G Router

Name: Peplink Balance 5000 EC 100G Enterprise Router
Brand: Peplink
SKU: BPL-5000-EC-100G-PRM
Price: 41398.96 USD
Availability: BackOrder

BPL-5000-EC-100G-PRM is the Balance 5000 EC (100G) enterprise router for large-scale multi-WAN, multi-site and multi-cloud network deployments. It provides 110 Gbps router throughput and up to 30 Gbps SpeedFusion VPN throughput with or without 256-bit AES encryption. SpeedFusion features include bandwidth bonding, Hot Failover and Smoothing for protected WAN connectivity. The configurable interface design supports up to eight 2.5G Ethernet WAN connections, up to nine 2.5G Ethernet LAN connections, up to eight 25G SFP28 interfaces and up to two 100G QSFP28 interfaces. Default 100G configuration assigns Ethernet ports 3 through 8, SFP28 ports 3 and 4, and QSFP28 port 2 to WAN; Ethernet ports 1 and 2, SFP28 ports 1 and 2, and QSFP28 port 1 are assigned to LAN. WAN/LAN configuration can be changed in Web Admin. For continuity planning, the chassis provides dual hot-swap power supplies, High Availability and LAN Bypass. It includes 2x 1TB SSDs for edge computing, with Docker and KVM virtual-machine hosting support. InControl 2 central management, Full content filtering, LACP NIC bonding, a stateful firewall and up to 800 IPsec tunnels support centralized enterprise operations. The 1U rack-mount platform uses AC input from 110V to 220V and includes two power cords, an Ethernet cable, rack-mount rails and a short-ear rack-mount kit. It is rated for operation from 0° to 40° C and carries a 1-Year Limited Warranty.

Ideal For

Enterprise data-center core routing
Multi-site SD-WAN and SpeedFusion VPN aggregation
High-speed regional hub and cloud on-ramp connectivity
Edge application hosting with Docker and KVM

Why This Product

1Uses 100G QSFP28 interfaces rather than the 40G QSFP+ interfaces on the Balance 5000 EC (40G).
2Provides 110 Gbps router throughput versus 70 Gbps for the Balance 5000 EC (40G).
3Uses two 25G SFP28 LAN ports and two 25G SFP28 WAN ports in its default physical configuration, while the 40G model shows four of each.

Design

Form Factor

Rack-mountable

General

Model	Balance 5000 EC (100G)
Warranty	1-Year Limited Warranty
Part Number	BPL-5000-EC-100G-PRM
Recommended Users	10,000 - 20,000+ recommended users
Router Throughput	110 Gbps

Support

Warranty Years

1 Year

Features

Firewall Integrated

Yes

Connectivity

Ethernet Technology

100 Gigabit Ethernet

Router Ports

Wan Ports

Package Contents

Included Items

Router, 2x power cords, Ethernet cable, rack-mount rails and short-ear rack-mount kit

Vpn And Security

Ipsec Tunnels	800 IPsec tunnels
Content Filtering	Full content filtering
Stateful Firewall Throughput	110 Gbps stateful firewall throughput
Speedfusion Vpn Throughput 256 Bit Aes	30 Gbps SpeedFusion VPN throughput, 256-bit AES
Speedfusion Vpn Throughput No Encryption	30 Gbps SpeedFusion VPN throughput, no encryption

Security Features

Sd Wan Support

Yes

Power And Physical

Weight	52.8 lb / 24 kg
Dimensions	17.2 x 25.6 x 1.73 in / 438 x 650 x 44 mm
Rack Mount	1U rack-mount
Power Input	AC input 110V - 220V
Power Supply	Dual hot-swap power supplies
Power Consumption	203W nominal, 595W maximum

Wan Lan Interfaces

Usb Wan	2x USB WAN
Ethernet Lan	Up to 9 x 2.5G Ethernet LAN
Ethernet Wan	Up to 8 x 2.5G Ethernet WAN
Sfp28 Wan Lan	Up to 8 x 25G SFP28 WAN/LAN
Qsfp28 Wan Lan	Up to 2 x 100G QSFP28 WAN/LAN

Edge And Management

Edge Computing	Application, Docker and KVM edge computing
Internal Storage	2x 1TB SSD
Central Management	InControl 2
Maximum Ap Supported	Up to 2,000 APs supported

Environmental And Compliance

Humidity	10% to 90% non-condensing
Certifications	FCC, CE and RoHS
Operating Temperature	0° to 40° C

Purchasing this for your business?

Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.

Wholesale pricing below retail

Net-30 terms for qualified businesses

Volume discount tiers

Dedicated account representative

Saved payment methods & PO support

Priority order processing

Create Free Business Account

Documentation

Peplink Balance 5000 Ec Datasheet

1.8mb

Frequently Asked Questions

Which Balance 5000 EC variant does this ordering code identify?▾

BPL-5000-EC-100G-PRM identifies the Balance 5000 EC (100G) configuration. This version supports up to two 100G QSFP28 WAN/LAN interfaces and has 110 Gbps router throughput. Its QSFP28 ports support 100G QSFP28 transceivers only.

What interfaces are available on the Balance 5000 EC (100G)?▾

The router supports up to eight 2.5G Ethernet WAN interfaces, up to nine 2.5G Ethernet LAN interfaces, up to eight 25G SFP28 interfaces, up to two 100G QSFP28 interfaces and two USB interfaces. SFP and Ethernet ports can be configured for WAN or LAN use.

What SpeedFusion performance and resiliency features are supported?▾

SpeedFusion VPN throughput is rated at 30 Gbps with no encryption and 30 Gbps with 256-bit AES encryption. Supported SpeedFusion features include bandwidth bonding, Hot Failover and Smoothing. The platform also supports High Availability and LAN Bypass for continuity planning.

What is included with the Balance 5000 EC (100G)?▾

Package contents are one Balance 5000 EC (100G), two power cords, one Ethernet cable, one set of rack-mount rails and one short-ear rack-mount kit with screws. The chassis is a 1U rack-mount design with dual hot-swap power supplies.

Can the router run edge applications and be centrally managed?▾

Yes. The platform includes 2x 1TB SSDs for edge computing and supports Application, Docker and KVM workloads. InControl 2 provides central management, while the router also supports Peplink AP Series management and remote AP and multiple configuration-profile management.
