The NWC27U2436SFBK is a 27U sealed wall-mount equipment cabinet from the NWC Series, built for IT and industrial teams that need rack-mounted network or automation gear protected from dust, dirt and dripping liquids. This is the "F" (filtered) configuration in RAL9005 Black with a solid door, supplied with rear and door Type 12 exhaust filters that maintain the UL Type 12 rating and are compatible with optional fan kits.
Construction is 14-gauge welded steel with a black textured powder coat finish (GREENGUARD Gold, TSCA and RoHS compliant). The cabinet is UL2416 Type 12 rated to a 350 lb (158 kg) load and seismic rated to a 200 lb (90.72 kg) dynamic load (Ip = 1.5) in accordance with IBC 2018, CBC 2019, NBC 2018, ASCE 7-16 and ASCE 7-10. It has been independently tested to IEC 60529 IP56 for protection against dust ingress and powerful water jets, and gasketed doors keep the enclosure sealed.
Overall dimensions are 58.02 in (1474 mm) high x 24.50 in (622 mm) wide x 36.22 in (920 mm) deep, with 48.00 in (1219 mm) of usable mounting height and 30.00 in (762 mm) of usable depth using the swing-out function (26.55 in / 674 mm maximum equipment depth). Two pairs of adjustable, EIA-compliant tapped 10-32 mounting rails accept standard 19-inch equipment, and a starter hardware pack with SCREW1032-50 screws is included.
The double-hinged design gives dual access for installation and servicing, while external mounting feet and the rear pan support secure wall installation and cable entry. Dedicated bonding and grounding points are provided. NWC27U2436SFBK is TAA-compliant, made in Canada, meets PCI DSS compliance requirements, and falls under UL file E474597.
| Series | NWC Series Environmental Wall-Mount Cabinet, Type 12, IP56 (350 lb) |
| Rack Type | Enclosed Wall Rack |
| Door Style | Solid door |
| Rack Units | 27U |
| Description | 27U 24W 36D NWC SOLID FILTERS |
| Part Number | NWC27U2436SFBK |
| Configuration | "F" Version – Type 12 filters included (no climate control unit) |
| Nominal Size (H X W X D) | 51.89 in x 24 in x 36 in (1,318 mm x 610 mm x 914 mm) |
| Overall Depth | 36.22 in (920 mm) |
| Overall Width | 24.50 in (622 mm) |
| Overall Height | 58.02 in (1474 mm) |
| Usable Mounting Height | 48.00 in (1219 mm) |
| Maximum Equipment Depth | 26.55 in (674 mm) |
| Front View Cabinet Height (Drawing) | 51.88 in (1318 mm) |
| Usable Mounting Depth (With Swing-Out Function) | 30.00 in (762 mm) |
| Bonding & Grounding | Dedicated bonding and grounding points for all cabinet components |
| UPC | 623980013749 |
| UNSPSC | 43223306 |
| GTIN-14 | 00623980013749 |
| UPC W/O Check Digit | 62398001374 |
| Rail Type | Tapped 10-32 |
| Load Rating | UL2416 Type 12 rated to 350 lb (158 kg) |
| Mounting Rails | Two (2) pairs of adjustable 10-32 threaded rails, EIA compliant |
| Included Hardware | Starter hardware pack with SCREW1032-50 screws |
| Power Bar Mounting | Power bar mounting without using 'U' space |
| Rack Compatibility | 19" rack compatible |
| Seismic Load Rating | 200 lb (90.72 kg) dynamic load (Ip = 1.5) |
| Tariff Code | 9403.10.0040 |
| Shipping Weight | 270 lbs (122.47 kg) |
| Country Of Origin | CA (manufactured in North America) |
| Hinges | Concealed hinges; double-hinged cabinet design |
| Material | Mild steel, 14-gauge welded construction |
| Shipping Note | Solid door included; filters ship inside the cabinet |
| Wall Mounting | External mounting feet and rear pan design for cable entry |
| Finish / Color | RAL9005 Black, painted black textured powder coat |
| Finish Compliance | GREENGUARD Gold, TSCA, RoHS compliant powder coat |
| Included Components | 1x 24W 27U NWC rear assembly, 1x centre section, 1x solid door, 2x H1 panel rail LH, 2x H1 panel rail RH, 2x 6" exhaust filter T12, 1x 10" exhaust filter T12 |
| Sealing | Sealed enclosure with gasketed doors; protects against dust, dirt and dripping liquids |
| Cooling / Airflow | Rear and door Type 12 filters that maintain UL Type 12 rating; compatible with fan kits |
| Ingress Protection | IP56, independently tested to IEC 60529 (dust ingress and powerful water jets) |
| Enclosure Type Rating | UL Type 12 |
| ECCN | EAR99 |
| PCI DSS | Meets Payment Card Industry Data Security Standard compliance requirements |
| Standards | cULus, PCI, Zone 4, TAA-compliant |
| UL File # | E474597 |
| Load Standard | UL2416 Type 12 rated enclosure (350 lb load rating) |
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
| USMCA Compliant | Yes |
| Seismic Standards | IBC 2018, CBC 2019, NBC 2018, ASCE 7-16, ASCE 7-10 |
Business account holders on Wall Mount Cabinets typically save 26% vs. retail pricing. Create a free account to see your price.
No. This is the "F" version, which includes rear and door Type 12 filters that maintain the UL Type 12 rating and are compatible with fan kits. Fan kits (DNFK1AC120, DTFK1AC120E, DTFK1AC150) are separate, and the factory-installed 900–1300 BTU DTS3021A115LG air conditioner is only supplied on the "A" versions.
It is UL2416 Type 12 rated to a 350 lb (158 kg) load and seismic rated to a 200 lb (90.72 kg) dynamic load at Ip = 1.5, in accordance with IBC 2018, CBC 2019, NBC 2018, ASCE 7-16 and ASCE 7-10.
27U of rack space with 48.00 in (1219 mm) usable mounting height and 30.00 in (762 mm) usable depth using the swing-out function; maximum equipment depth is 26.55 in (674 mm).
Two pairs of adjustable, EIA-compliant tapped 10-32 rails are provided, and a starter hardware pack with SCREW1032-50 screws is included for equipment installation.
Yes. It is a sealed enclosure with gasketed doors, UL Type 12 rated and independently tested to IEC 60529 IP56 for protection against dust ingress and powerful water jets.
It is RAL9005 Black with a black textured powder coat finish and a solid door. A window door version (NWC27U2436WFBK) and RAL 7035 light gray versions are also part of the series.
