Teltonika Networks PR3PUUS3 9 W US wall power supply with a 4-pin DC output connector.

Teltonika Networks PR3PUUS3 US Power Supply, 9 W, 9 VDC 1.0 A with 4-Pin Connector

Name: Teltonika Networks PR3PUUS3 US Power Supply, 9 W, 9 VDC 1.0 A with 4-Pin Connector
Brand: TELTONIKA NETWORKS
SKU: PR3PUUS3
Price: 13.26 USD
Availability: InStock

TELTONIKA NETWORKS|

MPN: PR3PUUS3

UPC: 4779051840861

Low Stock (1 left)

$13.26$15.80

Request for QuoteCall 224-955-1644 for Sales

Free 2-Day ShippingArrives by Monday, Oct 5

Authorized Dealer — Full manufacturer warranty

Save 44% with a Business Account

Exclusive pricing and Net-30 terms. Sign in or create a free account.

Create Free Business Account

Key Features

9 W output: 9 VDC at 1.0 A
US Type A plug with 100–240 VAC, 50/60 Hz input
4-pin, 3 mm pitch output connector for Teltonika devices
Short circuit protection and 3000 VAC primary-to-secondary HIPOT rating
Rated MTBF of 50,000 hours

The PR3PUUS3 is Teltonika Networks' 9 W power supply for US outlets. It is built for IT teams and integrators running Teltonika routers, gateways, modems and switches, and it works as a spare, a replacement or a second adapter for a new site. The fixed US Type A plug accepts 100–240 VAC at 50/60 Hz, and the input range extends from 90 to 264 VAC and 47 to 63 Hz. Output is 9 VDC at 1.0 A through Teltonika's 4-pin, 3 mm pitch connector, and output voltage stays between 8.55 and 9.45 VDC. Teltonika's current compatibility list for this adapter covers Oxa; the RUT200, RUT202, RUT241, RUT260, RUT261, RUT271, RUT281, RUT301, RUT901, RUT906, RUT951, RUT951 PoE+, RUT956, RUT976, RUT981 and RUT986 routers; the TRB140, TRB141, TRB142, TRB145, TRB160 and TRB501 gateways; the TRM142, TRM282 and TRM500 modems; and the TSW110 switch. Standardizing on one adapter across these models simplifies spares management for multi-site fleets. The adapter includes short circuit protection. It is dielectric-tested at 3000 VAC from primary to secondary, has a maximum input inrush current of 40 A and carries a rated MTBF of 50,000 hours. It is certified to UL 60950-1, CSA C22.2 No. 60950-1-07 and 47 CFR FCC Part 15 Subpart B, and it has been tested against the IEC 62321 series of hazardous-substance standards. A PR3PUUS3 datasheet is available.

Ideal For

Spare or replacement adapter for Teltonika RUT-series cellular routers
Powering TRB-series gateways and TRM-series modems in IoT deployments
Standardized power spares for multi-site branch and retail rollouts
Powering a TSW110 switch alongside a Teltonika router in a small network cabinet

Why This Product

1US Type A plug version of Teltonika's 9 W adapter, for North American outlets
29 VDC 1.0 A output with Teltonika's 4-pin, 3 mm pitch connector
3Covers a broad current lineup, from the RUT200 to the RUT986, the TRB and TRM series, and the TSW110

Other

Mtbf	50,000 h
Hipot	Primary to Secondary 3000 VAC
Certification	UL 60950-1; CSA C22.2 No. 60950-1-07; FCC Part 15 Subpart B; ANSI C63.4:2014; IEC 62321 series
Input Voltage Range	90 – 264 VAC
Input Frequency Range	47 – 63 Hz
Psu Efficiency Standard	DoE Level VI
Short Circuit Protection	Yes
Maximum Input Inrush Current	40 A
Output Voltage Maximum Deviation	8.55 – 9.45 VDC

General

Mpn	PR3PUUS3
Upc	4779051840861
Brand	Teltonika Networks
Model	US Power Supply, 9 W
Hs Code	HS 850440
Hts Code	HTS 8504.40.95

Package

Shipping Weight

0.22 lb

Compatibility

Compatible Products

Oxa, RUT200, RUT202, RUT241, RUT260, RUT261, RUT271, RUT281, RUT301, RUT901, RUT906, RUT951, RUT951 PoE+, RUT956, RUT976, RUT981, RUT986, TRB140, TRB141, TRB142, TRB145, TRB160, TRB501, TRM142, TRM282, TRM500, TSW110

Technical Data

Input Current	0.4 A
Input Voltage	100 – 240 VAC
Output Current	1.0 A
Output Voltage	9 VDC
Input Connector	US (Type A)
Input Frequency	50 / 60 Hz
Output Connector	4-pin, 3 mm pitch

Purchasing this for your business?

Business account holders on Power Cables typically save 44% vs. retail pricing. Create a free account to see your price.

Wholesale pricing below retail

Net-30 terms for qualified businesses

Volume discount tiers

Dedicated account representative

Saved payment methods & PO support

Priority order processing

Create Free Business Account

Documentation

PR3PUUS3 Datasheet

0.3mb

Frequently Asked Questions

Which Teltonika devices does the PR3PUUS3 power supply support?▾

Teltonika's current compatibility list includes Oxa; the RUT200, RUT202, RUT241, RUT260, RUT261, RUT271, RUT281, RUT301, RUT901, RUT906, RUT951, RUT951 PoE+, RUT956, RUT976, RUT981 and RUT986; the TRB140, TRB141, TRB142, TRB145, TRB160 and TRB501; the TRM142, TRM282 and TRM500; and the TSW110.

What is the output of this adapter?▾

It outputs 9 VDC at 1.0 A (9 W) through a 4-pin, 3 mm pitch connector. Output voltage stays within 8.55–9.45 VDC.

Can it be used on 230 V power?▾

The input accepts 100–240 VAC at 50/60 Hz, with an input range of 90–264 VAC. The plug is a US Type A plug.

Does the adapter have protection features?▾

Yes. It has short circuit protection and a 3000 VAC primary-to-secondary dielectric withstand rating, and it carries a rated MTBF of 50,000 hours.
