| Emea 5g | n1, n3, n28, n77, n78 |
| Emea Lte | B1, B3, B7, B20, B28, B42, B43, B46 |
| North America 5g | n2, n5, n12, n25, n26, n41, n48, n66, n71, n77 |
| North America Lte | B2, B4, B5, B7, B12, B13, B14, B17, B25, B26, B29, B30, B41, B46, B48, B66, B71 |
| Mpn | PRO8H4L2WBG15B |
| Brand | Parsec |
| Color | Radome Color: Black |
| Design | Patented |
| Elements | 4 cellular, 2 Wi-Fi, 1 Bluetooth, 1 L1 GPS |
| Product Line | Husky PRO Series |
| Product Type | Multi-element 5G antenna |
| Configuration | 8:1 (8 elements in one housing) |
| Country Of Origin | United States |
| Shipping Weight | 6.35 lb |
| Polarization | Linear |
| Max Input Power | 10 W |
| Test Conditions | Measured on a 2 ft x 2 ft ground plane; isolation, return loss and peak gain exclude cable loss |
| Isolation Wifi 2400 | 18 dB |
| Peak Gain Wifi 2400 | 7 dBi |
| Return Loss Wifi 2400 | Return Loss 50 Ω, Wi-Fi, 2400–2483.5 MHz: 15 dB |
| Isolation Cell 617 894 | 10 dB |
| Peak Gain Cell 617 849 | Peak Gain, CELL 1–4, 617–849 MHz: 5 dBi |
| Peak Gain Cell 849 894 | Peak Gain, CELL 1–4, 849–894 MHz: 4 dBi |
| Isolation Cell 1710 2200 | 16 dB |
| Isolation Cell 2200 2700 | 17 dB |
| Isolation Cell 3300 4000 | 20 dB |
| Isolation Cell 5150 5925 | 20 dB |
| Isolation Wifi 4900 5900 | 21 dB |
| Peak Gain Cell 1710 2200 | Peak Gain, CELL 1–4, 1710–2200 MHz: 5.5 dBi |
| Peak Gain Cell 2200 2700 | Peak Gain, CELL 1–4, 2200–2700 MHz: 8 dBi |
| Peak Gain Cell 3300 4000 | Peak Gain, CELL 1–4, 3300–4000 MHz: 7 dBi |
| Peak Gain Cell 5150 5925 | Peak Gain, CELL 1–4, 5150–5925 MHz: 9 dBi |
| Peak Gain Wifi 4900 5900 | 8 dBi |
| Return Loss Cell 617 698 | Return Loss 50 Ω, CELL 1–4, 617–698 MHz: 7 dB |
| Return Loss Cell 698 894 | Return Loss 50 Ω, CELL 1–4, 698–894 MHz: 8 dB |
| Return Loss Cell 1710 2700 | Return Loss 50 Ω, CELL 1–4, 1710–2700 MHz: 12 dB |
| Return Loss Cell 3300 4000 | Return Loss 50 Ω, CELL 1–4, 3300–4000 MHz: 8 dB |
| Return Loss Cell 5150 5925 | Return Loss 50 Ω, CELL 1–4, 5150–5925 MHz: 4 dB |
| Return Loss Wifi 4900 5900 | Return Loss 50 Ω, Wi-Fi, 4900–5900 MHz: 8 dB |
| Radiated Efficiency Wifi 2400 | Radiated Efficiency, Wi-Fi, 2400–2483.5 MHz: 80% |
| Radiated Efficiency Cell 617 849 | Radiated Efficiency, CELL 1–4, 617–849 MHz: 70% |
| Radiated Efficiency Cell 849 894 | Radiated Efficiency, CELL 1–4, 849–894 MHz: 60% |
| Radiated Efficiency Cell 1710 2200 | Radiated Efficiency, CELL 1–4, 1710–2200 MHz: 80% |
| Radiated Efficiency Cell 2200 2700 | Radiated Efficiency, CELL 1–4, 2200–2700 MHz: 75% |
| Radiated Efficiency Cell 3300 3700 | Radiated Efficiency, CELL 1–4, 3300–3700 MHz: 80% |
| Radiated Efficiency Cell 3700 4000 | Radiated Efficiency, CELL 1–4, 3700–4000 MHz: 70% |
| Radiated Efficiency Cell 5150 5925 | Radiated Efficiency, CELL 1–4, 5150–5925 MHz: 70% |
| Radiated Efficiency Wifi 4900 5900 | Radiated Efficiency, Wi-Fi, 4900–5900 MHz: 70% |
| Sma Wrench | PTA0194 |
| Star Washer | 1.5 in Star Washer: PTA0257 |
| Ground Plane | Ground Plane with Adhesive Back, 20 x 20 in: PTA0587 |
| Roof Mount Kit | PTA0610 |
| Shaft Extender | 1.5 in – 6 in Shaft Extender: PTA0635C |
| Pole Mount Bracket | PTA0149H |
| Replacement Magnets | PTA0212-2 |
| Lightning Arrestor N | PTA0736 |
| Hardware Kit 1 5 Shaft | Hardware Kit for 1.5 in Shaft, Nut/Washer: PTA0761 |
| Lightning Arrestor Sma | PTA0476 |
| Pole Mount Marine Black | Pole Mount Bracket, Marine Grade, Black: PTA0149H-MG-B |
| Pole Mount Marine White | Pole Mount Bracket, Marine Grade, White: PTA0149H-MG-W |
| Replacement Rooftop Gasket | PTA0187 |
| Pole Mount Horizontal Truss | Pole Mount Bracket, Horizontal Truss Mounting: PTA0149H-F |
| Wifi | 2400–2483.5, 4900–5900 MHz |
| L1 Gps | 1575.42 MHz |
| Cellular 4g 5g | 4G/5G Cellular: 617–894, 1710–2700, 3300–4000, 5150–5925 MHz |
| Routers | Compatible with: Cradlepoint R1900 Series Routers |
| Polarization | GPS Polarization: RHCP |
| Rf Connector | GPS RF Connector: SMA(M) |
| Rf Cable Type | GPS RF Cable: LSR100 |
| Preamp Current | GNSS Preamp Current: < 45 mA |
| Preamp Voltage | GNSS Preamp Voltage: 3 to 5 V |
| L1 Antenna Preamp Gain | L1 (1563–1587 MHz) Antenna + Preamp Gain: 28 dBic |
| L5 Antenna Preamp Gain | L5 (1164–1189 MHz) Antenna + Preamp Gain: 26 dBic (L1/L5 dual-band configurations only) |
| Mimo | 4x4 cellular |
| Categories | Enterprise, Mobile, Industrial |
| Mount Type | Roof Mount |
| Applications | Ambulances, Command Centers, School Buses, Shipping Containers, Trucks, RVs |
| Antenna Pattern | Omni-Directional |
| Available Colors | Black and White |
| Mounting Accessories Available | Pole Mount, Mag Mount |
| Mounting | Single 1.5 in |
| Dimensions | 10.75 in diameter x 2.23 in height (5.34 in with optional magnetic mount) |
| Connector Gps | GPS Connector: SMA(M) |
| Cable Type Gps | GPS Cable: LSR100 |
| Connector Wifi | Wi-Fi Connector: RP-SMA(M) |
| Cable Type Wifi | Wi-Fi Cable: LSR200 |
| Radome Material | Plastic with UV Additive |
| Rf Cable Length | 15 ft |
| Connector Cellular | Cellular Connector: SMA(M) |
| Ingress Protection | IP67 Waterproof |
| Cable Type Cellular | Cellular Cable: LSR200 |
| Operating Temperature | -40 °C to 85 °C |
Business account holders on Antennas typically save 23% vs. retail pricing. Create a free account to see your price.
It is listed as compatible with Cradlepoint R1900 Series routers. Its four SMA(M) cellular leads support 4x4 MIMO 4G/5G, and the two RP-SMA(M) Wi-Fi leads serve the router's Wi-Fi radio.
Yes. Parsec designs the Husky for both mobile and enterprise use, including fixed wireless. It mounts on a roof through a single 1.5 in hole, and pole mount brackets are available.
The enclosure is IP67 rated, the radome is plastic with a UV additive, and the operating range is -40 °C to 85 °C.
This configuration has 15 ft cables. Cellular and GPS leads use SMA(M) connectors and Wi-Fi leads use RP-SMA(M). The cellular and Wi-Fi cables are LSR200, and the GPS cable is LSR100.
The cellular elements cover 617–894, 1710–2700, 3300–4000 and 5150–5925 MHz. This includes North American bands such as B12, B13, B14, B66, B71, n41, n71 and n77, plus EMEA bands.
