Create Free Business AccountThe 265Z5 is the 450 VA model of the 265 Series low-voltage, filament high-current transformers, supplying 5 V center-tapped at 90 A from a dual 117/234 VAC primary. It is the part in the series ordering table flagged with 5 kV insulation, which makes it the option to look at when a heavy 5 V winding needs added insulation.
The ordering table lists the 265Z5 as the largest single-secondary model (450 VA) and marks it "* 5kV Insulation". The primary is a 117/234 VAC, 50/60 Hz dual primary, so the transformer can be applied to equipment running on either line voltage. The secondary is rated 5 C.T. at 90 A RMS, giving a center-tapped 5 V winding for heavy filament or low-voltage loads.
Construction is open style on a 4 hole frame for chassis mounting, with minimum 6" long leads or copper tabs with holes. A dual bobbin design means no electrostatic shield is required, and Class B insulation (130 °C) is used. Units are hi-pot tested at 2,000V RMS, and this model is listed with 5kV insulation.
For compliance, the 265 Series is UL listed (# E207860) Type 3AH and CSA certified (# LR209651), and the 265Z5 is listed as RoHS and REACH compliant. Identifiers include UPC 623980186085 and UNSPSC 39121301.
| Series | 265 Series |
| Description | Transformer, low voltage filament high current, chassis mount, 450VA, 265 series |
| Part Number | 265Z5 |
| Series Name | Low Voltage, Filament High Current, Chassis Mount - 150 VA to 450 VA |
| Configuration | Dual primary - single secondary |
| Manufacturer Short Description | 115/230V [email protected]@100A |
| Primary | 117/234 VAC - 50/60 Hz, dual primary |
| Hi-Pot Test | 2,000V RMS |
| Power Rating | 450 VA |
| Insulation Note | 5kV Insulation |
| Secondary Current (RMS) | 90 A |
| Secondary Voltage (RMS) | 5 C.T. (center tapped) |
| UPC | 623980186085 |
| UNSPSC | 39121301 |
| Style | Open style, 4 hole frame chassis mount |
| Terminations | Minimum 6" long leads or copper tabs with holes |
| Bobbin Design | Dual bobbin - no electrostatic shield required |
| Insulation Class | Class B (130 °C) |
| UL | UL listed (# E207860) Type 3AH |
| CSA | CSA certified (# LR209651) |
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
The 265Z5 is rated 450 VA with a 5 C.T. secondary at 90 A RMS.
Yes. It has a 117/234 VAC, 50/60 Hz dual primary.
It is an open style transformer with a 4 hole frame for chassis mounting. Connections are minimum 6" long leads or copper tabs with holes.
The 265 Series ordering table marks the 265Z5 with "5kV Insulation". The series uses Class B insulation (130 °C) and units are hi-pot tested at 2,000V RMS.
The 265 Series is UL listed (# E207860) Type 3AH and CSA certified (# LR209651). The part is listed as RoHS and REACH compliant.
