1 mH 100 A DC Single Coil Chassis Mount Choke

The 195C100 is a heavy current, chassis mount choke from the 195 Series, a single coil inductor rated 1 mH at 100 A DC. It is built for engineers and integrators designing high current power supply filters, where an open core and coil inductor bolted to a chassis or panel is the practical way to smooth DC output.

For 100 A DC circuits needing 1 mH, the 195C100 offers 0.0036 ohm resistance and Class B insulation, with a 6.50 in (165 mm) dimension B and a 26 lb table weight.

The ordering table lists dimension A at 5.25 in (133 mm), B at 6.50 in (165 mm), C at 4.47 in (114 mm), D at 4.38 in (111 mm) and E at 5.13 in (130 mm), with mounting slots (G) of 0.28 x 0.56 in (7 x 14 mm). Shipping weight is 28.98 lbs (13.15 kg), and the series table lists 26 lbs. Inductance is measured at the rated D.C. current, and both inductance and resistance carry a 15% tolerance.

Mounting uses a 4-slot bracket, and connections are made to a screw terminal or heavy copper tabs with holes. The 195 Series is hipot tested at 2,500 VAC with a recommended maximum operating voltage of 600 VAC (winding to core), and is rated for operation from -40C to 85C and storage from -40C to 105C. The chokes are UL approved under Type 3AH, E207860, 30V7, and the 195C100 is listed as RoHS and REACH compliant. Class b insulation is listed in the ordering table.

For AC applications from 60 Hz to 10,000 Hz, the manufacturer points to its 197 Series instead.
