Create Free Business AccountThe 185C16 is a 25VA low voltage chassis mount power transformer from the 185 Series, built for global use with a dual 115/230 VAC primary and 50/60 Hz operation. It suits OEM engineers, panel builders and equipment designers who need one transformer that can be wired for either mains voltage.
The 185C16 is the 16V C.T. model of the 25VA C size, rated 1.6A in series or 8V at 3.2A in parallel. The dual secondaries are brought out for series or parallel connection, and the primaries are wired in parallel for 115V or in series for 230V.
Construction uses a dual bobbin with Class F insulation (155 degrees C), and the unit is 4,000 V RMS hipot tested. Dual use terminals accept either solder or quick connect termination; terminal lugs are listed at 0.19 in wide and 0.02 in thick.
The 185C16 measures 2.81 in wide, 2.22 in deep and 2.31 in high (71.4 x 56.4 x 58.7 mm) including the mounting feet, weighs 1.25 lbs and ships at 1.21 lbs (0.55 kg). It chassis mounts per mounting figure A, with a 2.37 in hole-to-hole width. Listings include C UL US recognition (E207860), TUV Type Approval and CE certification to IEC 950 (EN 60-742 Safety Isolating Transformers); it is RoHS and REACH compliant.
| Mounting Type | Chassis mount |
| Mounting Figure | A |
| Hole To Hole Mounting Depth | - |
| Hole To Hole Mounting Width | 2.37 in (60.2 mm) |
| Series | 185 Series (Low Voltage Chassis Mount - 25 VA to 175 VA, Global Use - 115/230 V Primary) |
| Description | Transformer, chassis mount, 115/230V, 25VA, 16V C.T. @1.6A, 185 Series |
| Product Type | Low voltage chassis mount power transformer |
| Short Description | POWER TX 25 VA 115/230VAC |
| Weight | 1.25 lbs / 0.6 kg |
| Overall Depth (Includes Mounting Feet) | 2.22 in (56.4 mm) |
| Overall Width (Includes Mounting Feet) | 2.81 in (71.4 mm) |
| Overall Height (Includes Mounting Feet) | 2.31 in (58.7 mm) |
| Primary | Dual primary 115/230 VAC |
| Frequency | 50/60 Hz |
| Hipot Test | 4,000 V RMS |
| Secondaries | Dual secondaries for series or parallel connections |
| Power Rating | 25 VA |
| Primary Pins | 1, 2, 5, 6 (115V: parallel connection; 230V: series connection) |
| Secondary Pins | 7, 8, 11, 12 (parallel or series connection) |
| Secondary VAC (RMS), Series | 16V C.T. @ 1.6A |
| Secondary VAC (RMS), Parallel | 8V @ 3.2A |
| UPC | 623980492056 |
| UNSPSC | 39121301 |
| Part Number | 185C16 |
| Shipping Weight | 1.21 lbs (0.55 kg) |
| Terminals | Dual use terminals (solder lug or quick connect) |
| Construction | Dual bobbin construction |
| Insulation Class | Class F (155 degrees C) |
| Terminal Lug Width | 0.19 in (4.7 mm) |
| Terminal Lug Thickness | 0.02 in (0.5 mm) |
| CE | CE certified to IEC 950 (Approved to EN 60-742 Safety Isolating Transformers) |
| TUV | TUV Type Approved |
| RoHS Compliant | Yes |
| UL Recognition | C UL US recognized (E207860) |
| REACH Compliant | Yes |
| Agency Listings (Part Drawing) | cURus, CE, and TUV |
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
At 25VA it delivers 16V C.T. @ 1.6A with the two secondaries in series, or 8V @ 3.2A with them connected in parallel.
Yes. It has a dual 115/230 VAC primary for 50/60 Hz operation: wire the primaries in parallel for 115V or in series for 230V.
Dual use terminals that work as solder lugs or quick connects. Terminal lugs are 0.19 in wide and 0.02 in thick.
It is 2.81 in wide, 2.22 in deep and 2.31 in high (71.4 x 56.4 x 58.7 mm) including the mounting feet, and chassis mounts per figure A with a 2.37 in hole-to-hole width. Weight is 1.25 lbs; shipping weight is 1.21 lbs (0.55 kg).
The 185 Series is C UL US recognized (E207860), TUV Type Approved and CE certified to IEC 950 (Approved to EN 60-742 Safety Isolating Transformers). This part is RoHS and REACH compliant.
