Create Free Business AccountThe 162H10 is a 20VA low-profile power transformer for printed circuit board mounting, built with a universal dual primary rated 115/230V and a 10V center-tapped secondary rated 2A RMS in series connection. Wired in parallel, the two secondary windings deliver 5V at 4.0A. It suits OEM engineers and designers who need one board-level transformer for equipment that may run from either 115V or 230V mains at 50/60 Hz.
Construction uses a split bobbin with dual, non-concentrically wound secondaries, which keeps primary-to-secondary coupling low so no electrostatic shield is required. Insulation is Class B (130 degrees C) and the part is hipot rated at 2,500V RMS; the drawing specifies the primary-to-secondary test as 2500V, 60Hz for 1 second. The unit is designed so that all windings must be used, and pin numbers are embossed on the bobbin flange for identification.
On the series mechanical table the H-size body measures 2.25 in long, 1.88 in wide and 1.44 in high, with a listed weight of 0.8 lbs; the shipping weight is 0.8 lbs (0.36 kg). It is a P.C. board mount design with industry standard pin spacing and two-hole mounting for #4 screws; mounting screws are not provided.
Electrical test acceptance criteria on the 162H10 drawing include a maximum excitation current of 91.2mA at 115V, 60Hz across pins 1–2, secondary no-load voltages of 6.118V on each winding (pins 5–6 and 7–8, ±2%), and DC resistance at 20°C of 69.51 Ω per primary winding and 0.227 Ω per secondary winding (±20%). The part is RoHS and REACH compliant and the series is c UL us recognized. A single 115V primary version of the same output is listed as 164H10.
| Mounting Type | P.C. board mount, industry standard pin spacing |
| Mounting Holes | Two hole mounting |
| Mounting Screw | #4 (mounting screws not provided) |
| Series | 162-164 Series, Low Voltage PCB Mount - Low Profile - 1.1 VA to 36 VA |
| Description | Transformer, low voltage PCB mount, low profile, 115/230V, 20VA, 10V C.T. @ 2A |
| Part Number | 162H10 |
| Product Type | Power transformer, low voltage PCB mount, low profile |
| Short Description | POWER TX 20VA 115/230 |
| Size Code (VA Size Letter) | H |
| Equivalent Single Primary (115V) Part | 164H10 |
| Width (W) | 1.88 in |
| Height (H) | 1.44 in |
| Length (L) | 2.25 in |
| Width W (Drawing) | 1.875 in ±0.030 |
| Length L (Drawing) | 2.250 in ±0.030 |
| Pin Size D (Drawing) | 0.041 in x 0.018 in ±0.005 |
| Dimension H (Drawing) | 1.410 in ±0.030 |
| Dimension A (Series Table) | 0.30 in |
| Dimension B (Series Table) | 0.40 in |
| Dimension C (Series Table) | 1.6 in |
| Dimension M (Series Table) | 1.5 in |
| Unit Weight (Series Table) | 0.8 lbs |
| Primary | Dual primary, 115/230V |
| Coupling | Low primary to secondary coupling, no electrostatic shield required |
| Frequency | 50/60 Hz |
| Power Rating | 20VA |
| Primary Pins | 1–2 (115V) and 3–4 (115V) |
| Secondary Pins | 5–6 and 7–8 |
| Secondary Windings | Dual winding secondaries, non-concentrically wound; all windings must be used |
| Secondary (RMS), Series | 10V C.T. @ 2A |
| Secondary (RMS), Parallel | 5V @ 4.0A |
| Secondary Winding Marking (Each Winding, Drawing) | 5V @ 2A |
| UPC | 623980260723 |
| UNSPSC | 39121301 |
| Drawing Revision | Rev. 0, released 03/27/24 |
| DC Resistance @ 20°C, Pins 1–2 | 69.51 Ω ±20% |
| DC Resistance @ 20°C, Pins 3–4 | 69.51 Ω ±20% |
| DC Resistance @ 20°C, Pins 5–6 | 0.227 Ω ±20% |
| DC Resistance @ 20°C, Pins 7–8 | 0.227 Ω ±20% |
| Excitation Current (Iex) @ 115V, 60Hz, Pins 1–2 | 91.2mA max |
| Primary Winding Voltage, Pins 3–4 (115V 60Hz On Pins 1–2) | 115.0V ±2% |
| Secondary No-Load Voltage, Pins 5–6 (115V 60Hz On Pins 1–2) | 6.118V ±2% |
| Secondary No-Load Voltage, Pins 7–8 (115V 60Hz On Pins 1–2) | 6.118V ±2% |
| Shipping Weight | 0.8 lbs (0.36 kg) |
| Bobbin | Low profile, split bobbin design |
| Pin Identification | Pin numbers embossed on bobbin flange |
| Hipot | 2,500V RMS |
| Insulation Class | Class B, 130 degrees C |
| Hipot Test, Primary - Secondary (Drawing) | 2500V, 60Hz, 1 SEC |
| Safety | c UL us recognized (series) |
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
Yes. It has a universal dual primary rated 115/230V for 50/60 Hz operation. If you only need 115V input, the single-primary equivalent is 164H10.
Connected in series the secondary gives 10V C.T. @ 2A (RMS); connected in parallel it gives 5V @ 4.0A. The transformer is rated 20VA and all windings must be used.
It is a P.C. board mount with industry standard pin spacing and two-hole mounting for #4 screws. Mounting screws are not provided.
The series mechanical table lists 2.25 in (L) x 1.88 in (W) x 1.44 in (H), with a weight of 0.8 lbs. Shipping weight is 0.8 lbs (0.36 kg).
No. The split bobbin design gives low primary to secondary coupling, so no electrostatic shield is required.
Class B insulation rated 130 degrees C, a 2,500V RMS hipot rating, c UL us recognition for the series, and RoHS and REACH compliance.
