Create Free Business AccountThe 1538M09 is an EMI/RFI choke from the 1538 Series, providing 10 uH (+/-10%) with a maximum DC current of 12 A. Built on a high saturation flux density ferrite rod, the series is described as ideal for filtering or energy storage inductors, for engineers specifying EMI/RFI chokes in power and signal designs.
Electrical ratings for the 1538M09 are a maximum DC resistance of 0.012 ohms and a self-resonant frequency of 21.7 MHz. Inductance is measured at 1 kHz with 0 A DC current, and the typical inductance change is less than 5% at twice rated current.
The 1538 series offers 10 uH in several current ratings. Alongside the 1538M09 at 12 A there are higher-current 10 uH versions (1538M16 at 16 A, 1538M22 at 20 A) and lower-current 10 uH versions (1538M02 at 9 A), so check the current your circuit will carry when selecting between them.
Physical size follows the series drawing dimensions: Dim. A 1.12 in (28 mm) maximum, Dim. B 0.64 in (16 mm) maximum, Dim. C 1.00 in (25 mm) typical and Dim. D 0.05 in (1 mm) typical. The 1 in long leads are tinned to within 1/8 in of the body.
The rated ambient temperature range is -60 C to +85 C. The 1538M09 is RoHS and REACH compliant, has a shipping weight of 0.1 lbs (0.05 kg), and is identified by UPC 623980300030 and UNSPSC 39121301.
| Series | 1538 Series EMI/RFI Chokes |
| Application | Ideal for filtering or energy storage inductors |
| Part Number | 1538M09 |
| Product Type | RF Choke, heavy duty hash choke |
| Long Description | RF Choke, heavy duty hash choke, inductance 10uH, DC current 12A, 1538 series |
| Short Description | RF CHOKE |
| Lead Length | 1 in |
| Dim. A (Maximum) | 1.12 in (28 mm) |
| Dim. B (Maximum) | 0.64 in (16 mm) |
| Dim. C (Typical) | 1.00 in (25 mm) |
| Dim. D (Typical) | 0.05 in (1 mm) |
| Inductance | 10 uH |
| Inductance Change | Typically less than 5% at twice rated current |
| Inductance Tolerance | +/-10% |
| Maximum D.C. Current | 12 A |
| Inductance Measurement | 1 kHz with 0 A D.C. current |
| Maximum D.C. Resistance | 0.012 ohms |
| Self-Resonant Frequency | 21.7 MHz |
| UPC | 623980300030 |
| UNSPSC | 39121301 |
| Shipping Weight | 0.1 lbs (0.05 kg) |
| Core | High saturation flux density ferrite rod |
| Leads | Tinned to within 1/8 in of body |
| Ambient Temperature Range | -60 C to +85 C |
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
10 uH (+/-10%) with a maximum DC current of 12 A.
21.7 MHz, with a maximum DC resistance of 0.012 ohms.
Inductance is measured at 1 kHz with 0 A DC; the typical inductance change is less than 5% at twice rated current.
Yes: 1538M02 (9 A), 1538M16 (16 A), 1538M22 (20 A). The 1538M09 is the 12 A version.
Dim. A 1.12 in (28 mm) max, Dim. B 0.64 in (16 mm) max, Dim. C 1.00 in (25 mm) typical, Dim. D 0.05 in (1 mm) typical, with 1 in leads tinned to within 1/8 in of the body.
An ambient temperature range of -60 C to +85 C.
