Wilson Electronics 951100 100 ft coiled black RG11 coax cable with F-Male connectors

Wilson Electronics 951100 100 ft Black RG11 Low-Loss Coax Cable, F-Male to F-Male

Name: Wilson Electronics 951100 100 ft Black RG11 Low-Loss Coax Cable, F-Male to F-Male
Brand: Wilson Electronics
SKU: 951100
Price: 63.92 USD
Availability: BackOrder

Wilson Electronics|

MPN: 951100

UPC: 811815021780

Available on Backorder

$63.92$119.99

Available on backorder — ships as soon as stock arrives

Request for QuoteCall 224-955-1644 for Sales

Save 16% with a Business Account

Exclusive pricing and Net-30 terms. Sign in or create a free account.

Create Free Business Account

Key Features

100 ft length
75 Ohm low-loss RG11 foam cable
13/32 in. diameter
F-Male connectors on both ends
Rated for indoor and outdoor use
Black jacket

The Wilson Electronics 951100 is a 100 ft run of 75 Ohm RG11 coax, 13/32 in. in diameter, with an F-Male connector on each end. It is a low-loss foam cable rated for both indoor and outdoor use, with a black jacket suited to exterior routing. Coax is an integral part of any signal booster installation. It runs from the outdoor donor antenna to the amplifier, then from the amplifier to the indoor broadcast antennas that distribute the boosted signal. The manufacturer notes this cable has around 1-2 dB of additional loss per 100 feet. It also notes that 75 Ohm cable does not handle as much cellular traffic as 50 Ohm, so high-user situations can see reduced data speeds. WilsonPro generally recommends keeping total cable length at or under 100 feet from the amplifier to any antenna. The right limit depends on outside signal strength, cable loss, loss through splitters and taps, and the coverage needed. With a strong outside signal of around -45 dB, a donor-to-amplifier run of about 150 feet can still leave the amplifier plenty to work with. To shorten the cable and re-terminate it, use an RG-11 stripping tool and an RG-11 crimper.

Ideal For

Long donor antenna to amplifier runs in rural homes and buildings
Amplifier to broadcast antenna runs across large floor plans
Outdoor cable routing from roof or mast-mounted antennas
Custom-length runs cut and terminated on site

Why This Product

1RG11 for longer runs than RG6
275 Ohm handles less cellular traffic than 50 Ohm cable in high-user sites
3100 ft length at 13/32 in. diameter

Cable

Color	Black
Diameter	13/32 in.
Impedance	75 Ohm
Cable Type	RG11 low-loss foam coax
Environment	Indoor and outdoor use
Cable Length	100 ft
Additional Loss	Around 1-2 dB additional loss per 100 ft

General

Mpn	951100
Brand	Wilson Electronics
Product Type	RG11 Low-Loss Coax Cable

Physical

Shipping Weight

5.9 lbs

Connectors

End 1	F-Male
End 2	F-Male
Termination Tools	RG-11 stripping tool and RG-11 crimper for re-termination

Purchasing this for your business?

Business account holders on Specialty Cables typically save 16% vs. retail pricing. Create a free account to see your price.

Wholesale pricing below retail

Net-30 terms for qualified businesses

Volume discount tiers

Dedicated account representative

Saved payment methods & PO support

Priority order processing

Create Free Business Account

Frequently Asked Questions

How much loss does this cable add?▾

The manufacturer states around 1-2 dB of additional loss per 100 feet of cable.

What is the recommended maximum cable length?▾

WilsonPro generally recommends 100 feet or less total from the amplifier to any antenna. With a strong outside signal of around -45 dB, a donor-to-amplifier run of about 150 feet can still work.

How do I shorten and re-terminate it?▾

Use an RG-11 stripping tool and an RG-11 crimper. Strip the cable, peel back the braided shield so it does not touch the center pin, then seat and crimp the RG-11 connector.

Is it suitable for outdoor use?▾

Yes. This low-loss foam cable can be used both indoors and outdoors.
