| Connector | 3-pin industrial DC power socket |
| Power Consumption | Idle: 1 W / Max: 1.5 W / PoE Max: 121 W |
| Input Voltage Range | 7 – 57 VDC, overvoltage protection: 60 Vmax, reverse polarity protection: 80 Vmax, surge protection: min 64.4V/max 71.2V breakdown voltage, 93.6V maximum reverse voltage @4.3A maximum reverse surge current |
| PoE-Out Input Voltage Range | 44 - 57 VDC |
| PoE Ports | Port 1- 4 |
| PoE Standards | IEEE 802.3af (PoE, Type 1) and IEEE 802.3at (PoE+, Type 2), Alternative A |
| PoE Max Power Per Port (At PSE) | 30 W |
| Total PoE Power Budget (At PSE) | 120 W |
| Ethernet | 5 x ETH ports, 10/100 Mbps, supports auto MDI/MDIX crossover |
| IEEE 802.3 Series Standards | 802.3i, 802.3u, 802.3x, 802.3az, 802.3p 802.3Q |
| Power | 1 x 3-pin industrial DC power socket |
| Ethernet | 5 x RJ45 ports, 10/100 Mbps |
| Grounding | Grounding terminal on power connector |
| Status LEDs | 1 x Power LED, 10 x ETH status LEDs |
| Profinet | Profinet Class A conformance (available with optional order code) |
| Operating Humidity | 5% to 95% non-condensing |
| Operating Temperature | -40 °C to 75 °C |
| Ingress Protection Rating | IP30 |
| Weight | 142 g |
| Casing Material | Anodised aluminium housing and panels |
| Mounting Options | Integrated DIN rail bracket |
| Dimensions (W X H X D) | 113 x 28 x 50 mm |
| Packer Buffer | 128 KB |
| Jumbo Frame Support | 9216 bytes |
| MAC Address Table Size | 2K entries |
| Bandwidth (Non-Blocking) | 10 Gbps |
| Regulatory | CE, UKCA, RCM, CB, FCC, IC, WEEE |
Business account holders on Industrial Switches typically save 5% vs. retail pricing. Create a free account to see your price.
Yes — its rated operating range is IP30.
Idle: 1 W / Max: 1.5 W / PoE Max: 121 W.
Yes. Every Teltonika Networks device we sell integrates with Teltonika RMS for remote management, monitoring, and configuration — see /products/rms for details.
Teltonika's wiki knowledge base carries the full datasheet, configuration guides, and firmware for the TSF000 — linked under Documents on this page.
Yes — we are an authorized Teltonika Networks partner. Every unit is genuine, new, and carries the full manufacturer warranty, with US-based support before and after the order.
