TELTONIKA NETWORKS RUT361200800

Name: Teltonika RUT361 Industrial 4G LTE Cat 6 Router with Wi-Fi, North America Version (RUT361200800)
Brand: TELTONIKA NETWORKS
SKU: RUT361200800
Price: 275.00 USD
Availability: InStock

Teltonika RUT361 industrial LTE Cat 6 router in an anodised aluminium housing with two LTE and two Wi-Fi antennas attached.

The Teltonika RUT361 is a robust cellular router for IoT applications that need uninterrupted connectivity in challenging environments. Order code RUT361200800 is the North America hardware version, supplied in the standard package with a US power supply. Teltonika lists PTCRB, AT&T and Verizon among its operator approvals. Its LTE Cat 6 module, 3GPP Release 12, supports carrier aggregation for up to 300 Mbps downlink and 50 Mbps uplink. This version covers LTE-FDD bands B2, B4, B5, B7, B12, B13, B14, B25, B26, B29, B30, B66 and B71, plus LTE-TDD B41 and B48. Two SMA connectors serve the included LTE antennas, and the status page reports a carrier aggregation indicator alongside RSRP, RSRQ and SINR. Two RP-SMA Wi-Fi antennas drive a 2x2 MIMO 802.11b/g/n access point for up to 50 users, and the router can also run as a Wi-Fi client. One WAN and one LAN 10/100 Mbps port handle wired links. Mobile, wired, Wi-Fi WAN and VRRP connections can each act as an automatic failover, with load balancing across WANs. RutOS provides firewalling, VLANs, 802.1x, a captive-portal hotspot, and BGP, OSPF, RIP and EIGRP routing. VPN support includes OpenVPN, IPsec, WireGuard, ZeroTier, DMVPN, GRE, L2TP, SSTP and Tinc. Industrial integration covers Modbus TCP, MQTT, BACnet/IP, OPC UA, DNP3 and DLMS, with data delivery to AWS IoT Core, Azure IoT Hub, Cumulocity and ThingWorx. Up to two configurable digital I/O on the power connector can trigger email, SMS or RMS events. The anodised aluminium housing measures 100 x 30 x 85 mm and weighs 243 g. The router operates from -40 °C to 75 °C and is rated IP30. It runs on 9 to 30 VDC and draws under 4.7 W at maximum. DIN rail, wall and flat-surface mounting are available with an additional kit.

Ideal For

Primary or failover LTE WAN for retail stores, branch offices and kiosks in North America
Industrial telemetry and SCADA links using Modbus TCP, DNP3, MQTT or OPC UA
Building management connectivity over BACnet/IP for HVAC and energy systems
Utility metering backhaul with DLMS client support
Remote camera, signage and field equipment sites needing Cat 6 throughput and VPN access

Why This Product

1LTE Cat 6 with carrier aggregation up to 300 Mbps downlink, double the Cat 4 RUT241's 150 Mbps
2North America band plan including B14, B66, B71 and B48, with PTCRB, AT&T and Verizon listed as operator approvals
3Two Wi-Fi antennas in 2x2 MIMO versus a single Wi-Fi antenna on the RUT241
4Up to 2 configurable digital I/O and low power draw (idle under 2.4 W, max under 4.7 W)

Rf

Standards

EN 300 328, EN 301 908-1/-2/-13

Api

Teltonika Networks Web Api	Teltonika Networks Web API (beta)
Teltonika Networks Web Api Beta Support	Expand your device's possibilities by using a set of configurable API endpoints to retrieve or change data. For more information, please refer to this documentation: https://developers.teltonika-networks.com

Vpn

Gre	GRE tunnel, GRE over IPsec
Sstp	SSTP client
Tinc	Tinc client and server with encryption, authentication and compression
Dmvpn	Scalable IPsec VPNs, Phase 2 and 3, Dual Hub
Ipsec	XFRM, IKEv1, IKEv2, 14 encryption methods (3DES, DES, AES128/192/256, AES-GCM variants)
Openvpn	Multiple clients and a server simultaneously, 27 encryption methods
Stunnel	TLS encryption proxy for existing clients and servers
Zerotier	ZeroTier VPN client
Pptp L2tp	Simultaneous client/server, L2TPv3, L2TP over IPsec
Wireguard	WireGuard client and server
Openvpn Encryption	27 ciphers including DES, 3DES, Blowfish, CAST5, RC2 and AES-128/192/256 in CBC, CFB, OFB and GCM modes

Dnp3

Supported Modes	Station, Outstation
Supported Connection	TCP

Other

Operator

PTCRB, AT&T, Verizon

Power

Connector	4-pin industrial DC power socket
Poe Passive	Passive PoE optional on different hardware
Power Consumption	Idle < 2.4 W, max < 4.7 W
Input Voltage Range	9-30 VDC, reverse polarity and surge/transient protection

Bacnet

Supported Modes	Router
Configuration Options	Multiple BACnet/IP interfaces, network number assignment, preconfigured BDT entries for BBMD
Supported Connection Types	IP

Mobile

Apn	Auto APN
Sms	SMS status and configuration, Email to SMS, SMS to Email, SMS to HTTP, SMS to SMS, scheduled SMS, autoreply, SMPP
Ussd	Send and read USSD messages
Bridge	Bridge between mobile ISP and LAN device
Status	IMSI, ICCID, operator, network type, CA indicator, band, RSSI, SINR, RSRP, RSRQ, EC/IO, RSCP, data usage, LAC, TAC, cell ID, ARFCN, UARFCN, EARFCN, MCC, MNC
Passthrough	Mobile WAN IP passed to LAN device
3gpp Release	Release 12
Multiple Pdn	Different PDNs for multiple network access and services
Mobile Module	4G LTE Cat 6 up to 300/50 Mbps; 3G up to 42/5.76 Mbps
Band Management	Band lock, used band status display
Block Allow List	Operator block/allow list by country or operator
Sim Pin Code Management	Set, change or disable SIM PIN

Modbus

Supported Modes	Server, Client
Custom Registers	Custom register block requests read/write to a file on the router
Supported Data Formats	8-bit INT/UINT; 16-bit INT/UINT; 32-bit float/INT/UINT (ABCD, DCBA, CDAB, BADC); HEX; ASCII
Supported Connection Types	TCP

Opc Ua

Supported Modes	Client, Server
Supported Connection Types	TCP

Safety

Standards	CE (EN 62368-1, EN IEC 62232, EN 50385), RCM, CB
Ordinary Locations Standards	CE (EN IEC 62368-1, EN IEC 62311, EN 50665), RCM, CB

General

Mpn	RUT361200800
Upc	4779051843213
Brand	Teltonika Networks
Model	RUT361
Package	Standard package with US PSU
Hardware Version	RUT361 2***** / North America

Network

Ddns	More than 77 providers, others configurable manually
Dhcp	Static/dynamic allocation, DHCP relay, server configuration, static leases with MAC wildcards
Sshfs	Mount remote file system via SSH
Hotspot	Captive portal, internal/external RADIUS, MAC auth, SMS and SSO authentication, landing pages, walled garden, user groups and limits, 9 customisable themes
Routing	Static, dynamic (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), policy-based routing
Firewall	Port forward, traffic rules, custom rules, TTL target customisation
Dns Over Https	DNS over HTTPS proxy
Load Balancing	Balance traffic over multiple WAN connections
Network Backup	VRRP, Wired, Wi-Fi WAN, Mobile, each usable as automatic failover
Port Management	View, enable/disable ports, auto-configuration, speed settings
Network Topology	Visual network topology map
Network Protocols	TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP(S), SFTP, FTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPnP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, WOL, VXLAN
Traffic Management	Real-time monitoring, signal charts, usage history
Firewall Status Page	Firewall statistics, rules and rule counters
Connection Monitoring	Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP link inspection
Voip Passthrough Support	H.323 and SIP-ALG NAT helpers
Qos Smart Queue Management	Priority queuing by source/destination, service, protocol or port; WMM, 802.11e

Package

Contents	RUT361, 18 W US PSU, 2 x LTE antennas, 2 x Wi-Fi antennas, 1.5 m Ethernet cable, SIM adapter kit, Quick Start Guide
Shipping Weight	1.40 lb

Ethernet

Lan	1 x LAN 10/100 Mbps, IEEE 802.3/802.3u/802.3az, auto MDI/MDIX crossover
Wan	1 x WAN 10/100 Mbps, IEEE 802.3/802.3u/802.3az, auto MDI/MDIX

Security

Vlan	Port and tag-based VLAN separation
802 1x	Port-based network access control server
Firewall	Preconfigured rules via WebUI, unlimited CLI configuration, DMZ, NAT, NAT-T, NAT64
Web Filter	Website block list and allow list
Access Control	Access control for SSH, Web interface, CLI and Telnet
Authentication	PSK, digital and X.509 certificates, TACACS+, internal/external RADIUS, login attempt blocking, password generator
Attack Prevention	DDoS prevention (SYN flood, SSH, HTTP/HTTPS) and port scan prevention
Certificate Manager	Create CA, server, client, Let's Encrypt and SCEP certificates
Mobile Quota Control	Mobile data limit, period, start time, warning limit, phone number

Wireless

Ssid Essid	SSID stealth mode, MAC-based access control
Travelmate	Forward hotspot landing page to connected device
Wifi Users	Up to 50 simultaneous connections
Wifi Security	WPA2-Enterprise (PEAP), WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE; AES-CCMP, TKIP, client separation, EAP-TLS, 802.11w PMF
Wireless Mode	802.11b/g/n (Wi-Fi 4), 2x2 MIMO, AP and STA modes
Wireless Mac Filter	Allowlist, blocklist
Wireless Qr Code Generator	QR code for password-free network join
Wireless Connectivity Features	802.11s mesh, 802.11r fast roaming, 802.11v, 802.11k

Dlms Cosem

Dlms Support	DLMS utility meter data exchange
Supported Modes	Client
Supported Connection Types	TCP

Input Output

Input	Up to 2 x configurable digital inputs (shared), 0-6 V low, 8-30 V high
Events	Email, RMS, SMS
Output	Up to 2 x configurable open collector outputs (shared), max 30 V, 300 mA
Io Juggler	I/O conditions trigger events

Mqtt Gateway

Modbus Mqtt Gateway

Send commands to and receive data from Modbus server via MQTT broker

Iot Platforms

Thingworx	Monitors WAN type and IP, operator, signal strength, network type
Aws Iot Core	AWS cloud interaction with AWS Jobs support
Azure Iot Hub	Data to Server integration, Direct method RutOS API calls, zero-touch provisioning via DPS
Cumulocity Cloud Of Things	Monitors device, WAN, cell ID, ICCID, IMEI, operator, signal; reboot and firmware upgrade actions

Classification

Hts	8517.62.00
Hs Code	851762

Data To Server

Protocol	HTTP(S), MQTT, Azure MQTT
Data To Server	Collect parameters from multiple sources and protocols and send to one server; custom Lua scripting

Frequency Bands

Lte Fdd	4G LTE-FDD: B2, B4, B5, B7, B12, B13, B14, B25, B26, B29, B30, B66, B71
Lte Tdd	4G LTE-TDD: B41, B48

Physical Interfaces

Ios	2 x configurable digital I/O on 4-pin power connector
Sim	1 x Mini SIM (2FF), 1.8 V/3 V, external holder
Power	1 x 4-pin power connector
Reset	Reboot / user default / factory reset button
Antennas	2 x SMA (LTE), 2 x RP-SMA (Wi-Fi)
Ethernet	2 x RJ45, 10/100 Mbps
Status Leds	2 x connection type, 3 x signal strength, 2 x Ethernet, 1 x power LED

Monitoring Management

Rms	Teltonika Remote Management System (RMS)
Sms	SMS status and configuration
Ssh	SSH v1, v2
Call	Reboot, status, mobile data on/off, output on/off, answer/hang-up timer, Wi-Fi on/off
Fota	Firmware update from server, automatic notification
Mqtt	MQTT broker, MQTT publisher
Snmp	SNMP v1/v2/v3, SNMP Trap, brute force protection
Modbus	Modbus TCP status/control
Tr 069	OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem
Web Ui	HTTP/HTTPS WebUI with status, configuration, FW update, CLI, troubleshooting, event/system/kernel logs
Json Rpc	Management API over HTTP/HTTPS

Operating Environment

Operating Humidity	10% to 90% non-condensing
Operating Temperature	-40 °C to 75 °C
Ingress Protection Rating	IP30

Emc Emissions Immunity

Cs	EN 61000-4-6:2014
Dip	EN IEC 61000-4-11:2020
Eft	EN 61000-4-4:2012
Esd	EN 61000-4-2:2009
Standards	EN 55032, EN 55035, EN IEC 61000-3-2, EN 61000-3-3, EN 301 489-1/-17/-52
Radiated Immunity	EN IEC 61000-4-3:2020
Surge Immunity Ac Mains Power Port	EN 61000-4-5:2014 + A1:2017

Firmware Configuration

Rms	Bulk FW/configuration updates
Fota	Update FW
Web Ui	FW update from file or server, configuration profiles and backup
Keep Settings	Update FW without losing configuration
Factory Settings Reset	Full factory reset to default configuration

Firmware Customisation

Package Manager	Install additional software packages
Operating System	RutOS (OpenWrt-based Linux OS)
Development Tools	SDK package with build environment
Gpl Customization	Custom branded firmware and WebUI
Supported Languages	Busybox shell, Lua, C, C++

Physical Specification

Weight	243 g
Casing Material	Anodised aluminium housing and panels
Dimensions W H D	100 x 30 x 85 mm
Mounting Options	DIN rail, wall, flat surface (additional kit required)

System Characteristics

Cpu	Mediatek 580 MHz MIPS 24KEc
Ram	128 MB DDR2
Flash Storage	16 MB serial NOR flash

Regulatory Type Approvals

Regulatory

CE, UKCA, FCC, IC, RCM, CB, WEEE, RoHS, REACH, MTCTE

Purchasing this for your business?

Business account holders on Cellular Gateways typically save 12% vs. retail pricing. Create a free account to see your price.

Wholesale pricing below retail

Net-30 terms for qualified businesses

Volume discount tiers

Dedicated account representative

Saved payment methods & PO support

Priority order processing

Create Free Business Account

Documentation

RUT361 Flyer

1.8mb

RUT361 Datasheet

4.0mb

RUT361 Wiki — Datasheet, Manuals & Firmware

Frequently Asked Questions

How fast is the RUT361?▾

Its LTE Cat 6 module supports up to 300 Mbps downlink with carrier aggregation and up to 50 Mbps uplink. It is built to 3GPP Release 12.

Which LTE bands does the North America version cover?▾

RUT361200800 supports LTE-FDD B2, B4, B5, B7, B12, B13, B14, B25, B26, B29, B30, B66 and B71, plus LTE-TDD B41 and B48.

Which operator approvals does Teltonika list for this version?▾

Teltonika lists PTCRB, AT&T and Verizon for the RUT361 North America version.

How is the RUT361 powered?▾

It runs on 9 to 30 VDC through a 4-pin industrial power connector, and an 18 W US power supply is included. Power draw is under 2.4 W at idle and under 4.7 W at maximum.

Does it have digital I/O?▾

Yes. It offers up to two configurable digital inputs or outputs, shared on the 4-pin power connector. They can trigger email, SMS or RMS events through the I/O juggler.
