| Passive PoE | Passive PoE input through LAN1; incompatible with IEEE 802.3af, 802.3at and 802.3bt |
| Input Voltage | 9–30 V DC |
| Power Connector | 4-pin industrial DC power socket |
| Input Protection | Reverse polarity protection and surge protection above 31 V DC for up to 10 microseconds |
| Power Consumption (W) | Maximum power consumption below 6.5 W |
| Form Factor | Compact industrial router enclosure |
| Casing Material | Aluminium housing with plastic panels |
| Mounting Options | DIN rail, wall or flat surface mounting; additional kits required |
| CPU | MediaTek MIPS 24KEc processor |
| RAM | 128 MB DDR2 RAM |
| Development | SDK, scripting, custom firmware development and additional software packages |
| CPU Frequency | 580 MHz |
| Flash Storage | 16 MB SPI flash |
| Operating System | RutOS, based on OpenWrt Linux |
| QoS | SQM and traffic priority controls by source, destination, service, protocol or port |
| DHCP | DHCP server and relay with static or dynamic address allocation |
| Routing | Static, dynamic and policy based routing |
| Dynamic DNS | More than 77 DDNS providers with manual configuration for others |
| IP Protocols | IPv4 and IPv6 |
| DNS Over HTTPS | DNS over HTTPS proxy |
| Port Management | Ethernet port state and speed configuration |
| Network Topology | Visual network topology |
| VoIP Passthrough | H.323 and SIP ALG NAT helpers |
| Remote File System | Remote file system mounting over SSH |
| Traffic Monitoring | Real-time monitoring, signal charts and traffic usage history |
| Connection Monitoring | Link inspection and automatic reboot options |
| Redundancy And Tunneling | VRRP, VXLAN, PPP and PPPoE support |
| USSD | Send and read USSD messages |
| SIM Slots | 1 physical Mini SIM (2FF) slot with external holder; 1.8 V/3 V |
| Cellular Type | 4G LTE Cat 4 |
| SMS Functions | SMS messaging, forwarding, scheduling, autoreply and SMPP |
| Maximum 2G Rates | Up to 236.8 kbps download and upload |
| Maximum 3G Rates | Up to 21 Mbps download and 5.76 Mbps upload |
| APN Configuration | Automatic APN configuration |
| Mobile Diagnostics | Cellular operator, signal, band, cell and data usage monitoring |
| Maximum LTE Upload Rate | Up to 50 Mbps |
| Mobile Connection Modes | Routing, mobile bridge and mobile WAN IP passthrough |
| Mobile Network Controls | Band lock, operator filtering, SIM PIN management and multiple PDN support |
| Maximum LTE Download Rate | Up to 150 Mbps |
| Cellular Data Connectivity | 4G LTE, 3G and 2G |
| Load Balancing | Internet traffic balancing across multiple WAN connections |
| Failover Support | Automatic failover using mobile, wired, Wi-Fi WAN and VRRP options |
| Integrated Firewall | Port forwarding, traffic rules, custom rules, DMZ, NAT, NAT-T and NAT64 |
| UPC | 4779051849758 |
| Model | RUT241 |
| HS Code | 851762 |
| HTS Code | 8517.62.00 |
| Manufacturer | Teltonika Networks |
| Manufacturer Part Number | RUT241094000 |
| VLAN | Port and tag based VLAN separation |
| DMVPN | DMVPN Phase 2, Phase 3 and Dual Hub support |
| IPsec | XFRM IPsec with IKEv1, IKEv2 and 14 encryption methods |
| 802.1X | Port based network access control server |
| OpenVPN | Concurrent OpenVPN clients and server with 27 encryption methods |
| WireGuard | WireGuard client and server |
| VPN Supported | WireGuard, OpenVPN, IPsec and additional VPN or tunneling protocols |
| Web Filtering | Website allowlist and blocklist |
| Authentication | Key, certificate, TACACS+ and RADIUS authentication |
| Attack Prevention | Flood, login attack and port scan prevention |
| Mobile Quota Control | Mobile data limits and usage warnings |
| Certificate Management | Certificate creation and management |
| Management Access Control | Configurable access controls for management interfaces |
| Hotspot | Captive portal with authentication options, user limits and 9 customizable themes |
| Operating Modes | Access point and station modes |
| Wireless Security | Personal and Enterprise authentication, WPA3, OWE, EAP-TLS and protected management frames |
| Connection Assistance | QR code network joining and hotspot landing page forwarding |
| Wireless Access Controls | SSID hiding, MAC filtering and wireless client separation |
| Wireless Connectivity Features | Wireless mesh, fast roaming, BSS transition management, radio resource measurement and Relayd |
| Maximum Simultaneous Connections | Up to 50 simultaneous Wi-Fi connections |
| MQTT | MQTT broker and publisher |
| SNMP | SNMP v1/v2/v3 with traps and brute force protection |
| Logging | Event, system and kernel logs with remote logging support |
| Web API | Configurable API endpoints for retrieving and changing device data |
| IoT Platforms | IoT platform integrations including Azure provisioning and AWS Jobs |
| Firmware Updates | Local, server and RMS firmware updates with configuration retention |
| Remote Management | Teltonika Remote Management System compatibility |
| Management Interfaces | Local and remote management through WebUI, CLI and network management protocols |
| Configuration Management | Configuration profiles, backups, bulk updates and factory reset |
| Port Count | 2 RJ45 Ethernet ports |
| Wi-Fi Standard | Wi-Fi 4; IEEE 802.11b/g/n |
| Ethernet Technology | 10/100 Mbps Fast Ethernet |
| Ethernet Auto MDI/MDIX | Auto MDI/MDIX on WAN and LAN |
| Broadband Transmission Technology | Cellular, Ethernet and Wi-Fi WAN connectivity |
| Digital Input | 1 digital input; 0–6 V logic low, 8–30 V logic high |
| Digital Output | 1 open collector digital output; maximum 30 V, 300 mA |
| Event Handling | I/O conditions can trigger events with email, RMS and SMS notifications |
| I/O Connection | Digital input and output on the 4-pin power connector |
| LAN Ports | 1 RJ45 LAN port, 10/100 Mbps |
| WAN Ports | 1 RJ45 WAN port, 10/100 Mbps |
| Depth | 74 mm |
| Width | 83 mm |
| Height | 25 mm |
| Shipping Weight | 0.95 lb shipping weight |
| Weight (Approximate) | 125 g |
| Reset Button | Multifunction reboot and reset button |
| Status Indicators | Connection type, signal strength, LAN and power LEDs |
| Wi-Fi Antenna Connector | 1 RP-SMA Wi-Fi antenna connector |
| Cellular Antenna Connectors | 2 SMA LTE antenna connectors |
| DNP3 | DNP3 TCP station and outstation |
| BACnet | BACnet/IP routing with BBMD configuration |
| Modbus | Modbus TCP client and server with custom register support |
| OPC UA | OPC UA TCP client and server |
| DLMS/COSEM | DLMS/COSEM client for utility meter data exchange |
| Data To Server | Collect data from multiple sources and forward it to a server with Lua scripting support |
| Modbus Data Formats | Integer, floating point, HEX and ASCII formats with configurable byte ordering |
| Modbus MQTT Gateway | Modbus server commands and data through an MQTT broker |
| Operating Temperature | -40 °C to 75 °C |
Business account holders on Cellular Gateways typically save 13% vs. retail pricing. Create a free account to see your price.
RUT241 names the router model, while RUT241094000 identifies this ordering configuration. It combines LTE Cat 4 connectivity, Wi-Fi and two 10/100 Mbps Ethernet ports with a 4-pin industrial connector for DC power and digital I/O.
Yes. Automatic WAN failover supports mobile, wired and Wi-Fi WAN connections. Connection monitoring includes ping and other link inspection options, allowing the router to detect connectivity problems and use an alternate configured connection for the remote site.
Both Ethernet ports operate at 10/100 Mbps. Passive PoE input is available through LAN1 using Mode B spare pairs at 9–30 V DC. This power input is incompatible with IEEE 802.3af, 802.3at and 802.3bt PoE standards.
Connect Ethernet controllers through the LAN interface and use supported protocols such as Modbus TCP, BACnet/IP, OPC UA or MQTT. RMS provides remote management, while WireGuard, OpenVPN and IPsec offer VPN options. Digital I/O can trigger email, SMS or RMS events.
