| Mpn | PR1ICA70 |
| Upc | 4779051841639 |
| Brand | Teltonika Networks |
| Hs Code | HS 851771 / HTS 8517.71.00 |
| Product Type | Outdoor LTE & 5G/Wi-Fi/GPS combo antenna |
| Documents | Datasheet and Quick Installation Guide available |
| Shipping Weight | 3.50 lb |
| Gain | Max 4.5 dBi |
| Vswr | < 2.50 |
| Impedance | 50 Ω |
| Connectors | 4x SMA male |
| Polarisation | Vertical |
| Frequency Range | 617–960, 1700–2700, 3300–4300 MHz |
| Radiation Pattern | Omnidirectional |
| Gain | 28 dBi |
| Vswr | < 2.00 |
| Impedance | 50 Ω |
| Connectors | 1x SMA male |
| Polarisation | RHCP |
| Supply Voltage | 2.5–6.5 VDC |
| Frequency Range | 1560–1610 MHz |
| Current Consumption | 2.5–6.5 mA |
| Gain | Max 7.5 dBi |
| Vswr | < 2.00 |
| Impedance | 50 Ω |
| Connectors | 2x RP-SMA male |
| Polarisation | Vertical |
| Frequency Range | 2400–2500, 4700–6000 MHz |
| Radiation Pattern | Omnidirectional |
| Rutc50 Note | compatible; connect only the left and right Wi-Fi leads, leave the middle connector unused |
| Compatible Products | RUTM50, RUTM54, RUTX50 |
| Cable | 6x RG316, 1x RG174 |
| Weight | 1500 g |
| Ip Rating | IP68 |
| Rohs Compliant | Yes |
| Mounting Method | Wall, ceiling, mast |
| Operating Environment | Stationary installations only; not for moving objects or high-vibration environments |
| Operating Temperature | -40 °C to 75 °C |
Business account holders on Antennas typically save 23% vs. retail pricing. Create a free account to see your price.
Teltonika lists the RUTM50, RUTM54 and RUTX50 as compatible, and its product summary also mentions the RUTX12. It can be used with the RUTC50 with limited Wi-Fi performance.
The RUTC50 has three Wi-Fi connectors. Connect only the left and right Wi-Fi leads of the combo antenna and leave the middle router connector unused. Wi-Fi performance may be reduced compared with using all three.
No. Teltonika specifies this antenna for stationary installations only. It should not be used on moving objects or in high-vibration environments.
It has four SMA male connectors for 5G/LTE, two RP-SMA male connectors for Wi-Fi and one SMA male connector for GNSS.
It supports wall, ceiling and mast mounting. The housing is rated IP68 for outdoor exposure.
