| Form Factor | Plug-in card |
| Device Supported | HDD, SSD, ODD |
| Chipset Model | ASM1061 |
| Bracket Height | Full-height and low-profile |
| Chipset Manufacturer | ASMedia |
| Pcie Generation | PCIe 2.0 |
| Host Interface | PCIe 2.0 x1 |
| Energy Star | Not ENERGY STAR |
| Taa Compliant | TAA compliant |
| Controller Type | SATA controller |
| Compatible Rack Unit | 1U and larger |
| Raid Levels | No built-in RAID |
| Raid Ports | 2 ports |
| Raid Cache Gb | 0 GB |
| Raid Data Rate | 6 Gbps |
| Raid Max Drives | 2 drives |
| Raid Battery Backup | No battery-backed cache |
| Raid Controller Type | SATA controller adapter |
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
No built-in RAID is listed for this model. It is designed as a SATA expansion adapter rather than a hardware RAID controller.
The card supports HDD, SSD, and ODD devices through SATA and ATA/ATAPI compatibility.
It installs in a PCIe 2.0 x1 slot.
Yes. Full-height and low-profile brackets are included, which helps with both standard and compact chassis deployments.
