| Lna Gain | 26 dB |
| Gps Frequency Range | 1562-1612 MHz |
| Number Of Gps Elements | 1 module |
| Cable Fitting | Cables fitted |
| Cable Type Gps | FR RG174 |
| Cable Type Lte | FR RG174 / RG174 |
| Cable Type Wifi | FR RG174 / RG174 |
| Cable Length Gps | 5 m (16.4 ft) |
| Cable Length Lte | 5 m (16.4 ft) |
| Cable Length Wifi | 5 m (16.4 ft) |
| Quantity Cell Cable | 4 |
| Quantity Wifi Extension | 2 |
| Quantity Gps Gnss Extension | 1 |
| Mpn | LG-IN2445-W |
| Upc | 5055416055040 |
| Brand | Panorama Antennas |
| Colour | White |
| Configuration | 7-in-1: 4x4 MIMO cellular, 1 GPS/GNSS, 2x2 MIMO Wi-Fi |
| Product Family | Mako 5G dome (L[G]M[H]M4[B]-6-60[-24-58] family) |
| Shipping Weight | 5.55 lb |
| Ground Plane | Ground-plane independent; conductive or non-conductive surfaces |
| Mounting Methods | Magnetic, Panel |
| Mounting Type Temp | Magnetic |
| Mounting Type Fixed | Panel (single hole) |
| Ip Rating | IP69K, IK10 |
| Taa Compliant | TAA compliant |
| Cable Flammability | EN45545-2 HL3, UN ECE R118, EN6722 |
| Pattern | Omnidirectional |
| Uhf Elements | No |
| Wifi Elements | 2 x 2 MIMO |
| Max Input Power | 10 W |
| Frequency Range Gain | 617-960 MHz: 4 dBi; 1710-3800 MHz: 8 dBi; 4900-6000 MHz: 9 dBi |
| Cellular Lte Elements | 4 x 4 MIMO |
| Height | 80 mm (3.15 in) |
| Diameter | 180 mm (7.09 in) |
| Operating Temperature | -40 °C to +80 °C (-40 °F to +176 °F) |
| Technology | GPS, GNSS, 2G/3G/4G, 4G/5G, 5G, Band 71 600 MHz ready, FirstNet, Wi-Fi MIMO |
| Public Safety Networks | Suitable for FirstNet (USA) and ESN (UK) |
| Connector Gps | SMA (m) |
| Connector Lte | SMA (m) |
| Connector Wifi | Reverse Polarity SMA |
Business account holders on Antennas typically save 21% vs. retail pricing. Create a free account to see your price.
It is sold as a kit for Cradlepoint router installations. The cellular and GPS leads terminate in SMA (m) and the Wi-Fi leads in RP-SMA.
Yes, the LG-IN2445-W is TAA compliant.
It supports failover dual-SIM use, running the four cellular elements as two 2x2 pairs with one SIM active at a time. It is not intended for concurrent or aggregated dual-SIM operation.
It is a single-hole panel mount that does not need a ground plane. Panorama also lists accessories including the SAB-225 magnetic mount, SAB-342 pole/mast mount and LGMM-EXT-R-SLT thick or ribbed panel adapter.
