| Flash | 256M FLASH |
| Region | USA & CANADA |
| Series | SGX 5150 |
| Weight | 0.35 kg (0.77 lb) |
| Usb Port | Type C Host / Device Connector |
| Warranty | 5-Year Limited Warranty |
| Wireless | 802.11A/B/G/N/AC |
| Ip Rating | 30 |
| Poe Class | 3at Class 2 Powered Device |
| Dimensions | 10.8 cm (4.3 in) x 7.2 cm (2.8 in) x 3.3 cm (1.3 in) |
| Power Input | DC barrel, 9-30 VDC (standard) |
| Ethernet Port | RJ-45 Ethernet port, 10/100Mbps |
| Wireless Band | Dual band 2.4 GHz and 5 GHz |
| Wireless Mode | 1×1 AC (MCS0 – MCS9) |
| Relative Humidity | 5 to 95%, Non-condensing |
| Usb Specification | Configurable USB 2.0 HS/FS port with USB type C connector |
| Power Over Ethernet | Optional |
| Storage Temperature | -40° to 85° C (-40° to 185° F) |
| Operating Temperature | -40° to 70° C (-40° to 158° F) |
| Ethernet Surge Isolation | 1.5 KV Surge Isolation |
| Maximum Power Consumption | 5.5W max with USB Load |
| Typical Power Consumption | 1.9W typical without USB Load |
Business account holders on Cellular Gateways typically save 13% vs. retail pricing. Create a free account to see your price.
The Lantronix part-table description lists SGX5150222US for USA & CANADA.
The SKU is listed with wireless 802.11A/B/G/N/AC. SGX 5150 wireless specifications also list 1×1 ac, 1×1 n, and dual band 2.4 GHz and 5 GHz operation.
Specified inputs are DC barrel, 9-30 VDC (standard); Power over Ethernet (optional); and USB Type C I/O connector.
Management interfaces include Web Manager (HTML5 Browser HTTP/HTTPS), CLI over serial ports, telnet or SSH, OTA field upgrade, SNMP v2/V3, and XML Configuration records via CLI or FTP.
