| Weight | 0.35 kg (0.77 lb) |
| Usb Port | Type C Host / Device Connector |
| Warranty | 5-Year Limited Warranty |
| Data Rates | Up to 921 Kbps |
| Dimensions | 10.8 cm (4.3 in) x 7.2 cm (2.8 in) x 3.3 cm (1.3 in) |
| Power Input | DC barrel, 9-30 VDC (standard) |
| Flash Memory | 256 MB |
| Ethernet Port | RJ-45 Ethernet port, 10/100Mbps, 1.5 KV Surge Isolation |
| Wireless Band | Dual band 2.4 GHz and 5 GHz |
| Serial Interface | RS-232 (RJ-45) |
| Relative Humidity | 5 to 95%, Non-condensing |
| Usb Specifications | Configurable USB 2.0 HS/FS port with USB type C connector |
| Wireless Standards | IEEE 802.11a/b/g/n/AC |
| Storage Temperature | -40° to 85° C (-40° to 185° F) |
| Optional Power Input | Power over Ethernet (optional) |
| Operating Temperature | -40° to 70° C (-40° to 158° F) |
| Power Consumption Max | 5.5W max with USB Load |
| Ethernet Specifications | IEEE 802.3 MAC and PHY, 10BaseT and 100BaseT |
| Power Consumption Typical | 1.9W typical without USB Load |
Business account holders on Cellular Gateways typically save 13% vs. retail pricing. Create a free account to see your price.
SGX5150222ES is identified with wireless 802.11a/b/g/n/ac. The specifications list 5G Wi-Fi (IEEE 802.11ac), IEEE 802.11n, compatibility with IEEE 802.11a/b/g and support for IEEE 802.11d/h/j/i.
The SKU description lists RS232(RJ45), USB and 10/100 Ethernet. The specifications list a USB Type C Host / Device Connector and an RJ-45 Ethernet port, 10/100Mbps.
Management interfaces include Web Manager (HTML5 Browser HTTP/HTTPS), CLI over serial ports, telnet or SSH, SNMP v2 and V3, and XML configuration records via CLI or FTP.
The extended operating temperature is -40° to 70° C (-40° to 158° F).
