| Flash | 256M Flash |
| Weight | 0.35 kg (0.77 lb) |
| Usb Port | Type C Host / Device Connector |
| Ip Rating | 30 |
| Data Rates | Up to 921 Kbps |
| Dimensions | 10.8 cm (4.3 in) x 7.2 cm (2.8 in) x 3.3 cm (1.3 in) |
| Power Input | DC barrel, 9-30 VDC (standard) |
| Serial Port | 1xRS232 (RJ-45) |
| Ethernet Port | RJ-45 Ethernet port, 10/100Mbps |
| Led Indicators | System Status; Wi-Fi Wireless Signal Strength; Green/Red Simplified Diagnostics |
| Power Consumption | 1.9W typical without USB Load; 5.5W max with USB Load |
| Relative Humidity | 5 to 95%, Non-condensing |
| Usb Specifications | Configurable USB 2.0 HS/FS port with USB type C connector |
| Wireless Standards | 802.11a/b/g/n/AC |
| Power Over Ethernet | 3at Class 2 Powered Device |
| Storage Temperature | -40° to 85° C (-40° to 185° F) |
| Management Interfaces | Web Manager (HTML5 Browser HTTP/HTTPS); CLI (over serial ports, telnet or SSH); OTA Field upgradeable; Supports SNMP v2, V3; XML Configuration records via CLI or FTP |
| Operating Temperature | -40° to 70° C (-40° to 158° F) |
| Ethernet Specifications | IEEE 802.3 MAC and PHY, 10BaseT and 100BaseT |
Business account holders on Cellular Gateways typically save 13% vs. retail pricing. Create a free account to see your price.
Yes. This SKU is listed with wireless 802.11a/b/g/n/ac, and the SGX 5150 specifications include 5G Wi-Fi (IEEE 802.11ac).
The part-table row lists 1xRS232 (RJ45), USB, 10/100 Ethernet and PoE.
SGX 5150 supports Web Manager (HTML5 Browser HTTP/HTTPS), CLI over serial ports, telnet or SSH, OTA field upgrade, SNMP v2 and V3, and XML Configuration records via CLI or FTP.
The extended operating temperature is -40° to 70° C (-40° to 158° F).
