| Digital Input | 0–1 V DC = 0; 1.4–36 V DC = 1 |
| Digital Output | Open-collector digital output, 100 mA max, 36 V DC max |
| User Configurable Io | 2 user-configurable I/Os via the 4-pin Micro-Fit power connector (lower row) |
| Input Voltage | 8–32 V DC, with slow start |
| Power Off Timekeeping | Dedicated RTC, 100-day retention, approx. 15 mWh lithium manganese battery (not functional below -20 °C) |
| Rs232 | Full RS-232 on 9-pin sub-D |
| Rs485 | Isolated half/full-duplex RS-485 via SC485 Snap Cap (sold separately), 5-pin 3.5 mm COMBICON |
| Mpn | E214F002S |
| Upc | 783384240780 |
| Brand | Lantronix |
| Model | E214 – EMEA, Malaysia |
| Region | EMEA and Malaysia regional variant |
| Series | E210 Series |
| Shipping Weight | 0.39 lbs |
| Sim | Dual SIM, single standby (2x mini-SIM trays) |
| Fallback | 3G and 2G fallback |
| Lte Bands | LTE Cat-1 bands B1, B3, B7, B8, B20, B28 |
| Technology | 4G LTE Cat-1 |
| Ports | 2 Ethernet ports |
| Speed | 10/100 Base Ethernet |
| Configuration | 1x LAN + 1x WAN (reconfigurable as second LAN), RJ-45 with two LEDs |
| Weight | Approx. 150 g |
| Material | Brushed aluminum alloy |
| Mounting | DIN rail mountable |
| Dimensions | 92.5 x 57.2 x 22.5 mm (without connectors) |
| Status Leds | 7 LEDs: Power, SIM, Wi-Fi, Activity, Network, Signal, Alert |
| Sdk | G520 SDK (Python, C/C++) |
| Routing | DHCP, static routing, port forwarding, DDNS, DNS proxy, NAT, STP |
| Security | HTTPS UI, zone-based firewall, VLAN, DMZ, SIM PIN |
| Redundancy | Ethernet/cellular/Wi-Fi failover or load balancing |
| Resilience | Configurable network watchdog, internal application watchdog |
| Vpn Tunneling | PPTP client, L2TP, OpenVPN, GRE, IPsec (4 channels), WireGuard |
| Wifi Security | Client or AP (approx. 12 users); WEP, WPA, WPA2-PSK, WPA3-PSK |
| Administration | Web UI, setup wizard, console log viewer, config save/load, NTP, SMS/OTA config, TR-069 |
| Device Management | Lantronix Percepxion or third-party platforms |
| Industrial Protocols | Modbus, DNP3, IEC 60870-5-101/104, MQTT, Azure, Cumulocity converters; I/O via SMS |
| Performance Fault Management | Real-time CPU/interface load, traffic analysis, ICMP, traceroute, NS lookup |
| Cpu | MIPS32 24KEc CPU at 580 MHz |
| Ram | 128 MB DDR SDRAM |
| Flash | 32 MB SPI flash |
| User Storage | microSD slot (card not provided) |
| Gps | GPS available on G variants only |
| Storage | -40 °C to +85 °C, up to 95% RH |
| Operating | -20 °C to +70 °C, up to 95% RH |
| Wifi | 1T1R Wi-Fi 4 via RP-SMA antenna connector |
| Wifi Modes | Client or access point (approx. 25 users); WEP, WPA, WPA-PSK/WPA2-PSK |
Business account holders on Cellular Gateways typically save 13% vs. retail pricing. Create a free account to see your price.
Cert, Environmental, E210
0.1mb
Cert, MTBF Declaration, E214 Series
0.1mb
Certs RoHS and REACH, E210 & E220 Series
0.1mb
Cert, RoHS and REACH FM-418 A, Lantronix Mobility Solutions – FOX3
0.1mb
E210 Series – Product Brief
0.3mb
E210 Series – Product Brief (A4)
0.3mb
CERTIFICATE, E214#02, CE
0.2mb
Lantronix E210 Series Routers Case Study for ATM Monitoring Solutions – Argus Secure Technologies
0.7mb
E210 Series – User Guide
1.1mb
Lantronix Mobility Solutions Brochure
3.5mb
E214 & E218 Quick Start Guide Rev B
0.3mb
E210 and E220 Series – ePACK User Guide
8.0mb
This is the EMEA and Malaysia variant, with bands B1, B3, B7, B8, B20 and B28. For North America, Lantronix offers the E214G000S (AT&T, T-Mobile) and the E214G001S (Verizon).
The radio falls back to 3G and 2G. With two SIMs installed, it can also fail over to the second SIM, Ethernet WAN or Wi-Fi.
Lantronix's MF13 bundle for the E214 and E218 includes a KDC44 power cord, A32M0 and A21H0 antennas and a BR551 DIN rail clip. The SC485 Snap Cap adds isolated RS-485, and the P24E0 (Euro plug) and P24E4 (UK/HK plug) 12 V adapters are available.
Yes. It runs a Linux-based ePack environment, and the G520 SDK lets you build custom packages and firmware images in Python or C/C++.
