| Ignition | On power header |
| Configurable Io | User I/O: 2x (analogue in, 4-20 mA in, or digital out) |
| Host Port | USB: 1x Type-A host |
| Last Gasp | approx. 100 s (not functional below -10 °C) |
| Input Voltage | 10.8-60 V DC |
| Power Off Timekeeping | RTC: 100-day retention (not functional below -20 °C) |
| Rs232 | Full, DB9 |
| Rs485 | 5-pin COMBICON (sold separately) |
| Mpn | G526GP12S |
| Upc | 783384244429 |
| Brand | Lantronix |
| Model | G526 Industrial |
| Region | EMEA, Taiwan, Australia |
| Series | G520 |
| Features Summary | Dual SIM, microSD, Last Gasp, GNSS, Percepxion ready, SDK support |
| Interfaces Summary | 2x Ethernet, Wi-Fi 5, BT/BLE 5.1, 2x Serial, USB 2.0, 4x I/O, ignition sensing, CAN bus |
| Sim | Dual SIM, single standby, 2x mini-SIM holders |
| Lte Bands | B1, B3, B7, B8, B20, B28 |
| Technology | Cellular: 4G LTE Cat-4 |
| Fallback 3g 2g Bands | 3G/2G Fallback: B1, B3, B8 |
| Poe | Not on G526 (security variants only) |
| Ports | Ethernet Ports: 2x 10/100 RJ-45 |
| Speed | 10/100 Mbps |
| Configuration | 1 LAN + 1 WAN (reconfigurable as LAN) |
| Weight | approx. 300 g |
| Housing | Brushed aluminum alloy |
| Dimensions | Size: 131.5 x 81.27 x 25 mm (without connectors) |
| Status Leds | 9 |
| Shipping Weight | 1.03 lbs |
| Sdk | G520 SDK (Python, C/C++) |
| Vpn | IPsec (4 ch), OpenVPN, WireGuard, L2TP, GRE, PPTP |
| Routing | DHCP, static routes, NAT, DDNS, STP |
| Security | Zone firewall, VLAN, DMZ, HTTPS, SIM PIN |
| Redundancy | Failover or load balancing |
| Resilience | Connectivity and application watchdogs |
| Administration | Web UI, wizard, NTP, SMS/OTA config, TR-069 |
| Fault Management | Diagnostics: Traffic analysis, ICMP, traceroute, NS lookup |
| Device Management | Percepxion or third-party |
| Industrial Protocols | Modbus, DNP3, IEC 104/101, EtherCAT, DLMS |
| Cpu | ARM926EJ-S, 600 MHz |
| Ram | 256 MB DDR2 SDRAM |
| Spi Flash | 8 MB |
| Secure Element | Security variants only |
| External Storage | microSD (not provided) |
| Internal Storage | User Storage: 256 MB NAND Flash |
| Gps | Dedicated SMA connector |
| Storage | -40 °C to +85 °C, up to 95% RH |
| Operating | -30 °C to +70 °C, up to 95% RH |
| Wifi | 2T2R Wi-Fi 5, 2x RP-SMA |
| Roaming | Fast Roaming: 802.11r |
| Bluetooth | BT/BLE 5.1 |
| Wifi Modes | Client or AP (approx. 12 users) |
| Wifi Security | WEP, WPA, WPA-PSK/WPA2-PSK, WPA3-PSK |
Business account holders on Cellular Gateways typically save 13% vs. retail pricing. Create a free account to see your price.
CERTIFICATE, G526, UL
0.1mb
Environmental Certs RoHS and REACH_G520 series (G526, G527, G528)
0.1mb
CERTIFICATE, G526GP12S, AUS SDoC
0.1mb
CERTIFICATE, G526GP12S, CE DoC
0.3mb
Cert, UKCA Declaration of Conformity, G526GP12S
0.4mb
CERTIFICATE, G526, CB
0.2mb
Cert, MTBF, G520
0.6mb
G520 Product Brief – A4
0.4mb
G520 Product Brief Japanese
0.6mb
G520 Product Brief
0.4mb
CERT, TAIWAN NCC, G526GP12S
0.2mb
CERT, TAIWAN NCC, G526GP12S – 2
0.4mb
External IoT Gateways
0.2mb
G526 & G527 Quick Start Guide Rev D
0.5mb
CERT, TAIWAN NCC, G526GP12S -v7
0.7mb
G520 User Guide Rev H
4.6mb
This SKU is the EMEA, Taiwan and Australia variant, with LTE bands B1, B3, B7, B8, B20 and B28. For North American carriers, Lantronix offers the G526GP1AS variant.
No. It is an LTE Cat-4 gateway with 3G/2G fallback. 5G is offered on the G528 model of the G520 Series.
Modbus master, DNP3 Outstation, IEC 104 slave, IEC 101 master, EtherCAT and DLMS client.
It accepts 10.8 to 60 V DC. An ignition pin on the power header supports vehicle installations.
No. PSE-PoE+ output is a feature of the G520 security variants, not the G526 industrial model.
