| Emi | EN55032 Class A, EN55024 |
| Mtbf | 623,377 hrs |
| Depth | 6.45” [164 mm] |
| Width | 6.25” [159 mm] |
| Height | 1.75” [44 mm] |
| Safety | EN60950, UL 60950 |
| Weight | 1.8 lbs. [0.82 kg] |
| Warranty | 5 Years |
| Maximum Output | 345 Watts |
| Output 1 Voltage | 56V (terminal block) |
| Output 2 Voltage | 24V (terminal block) |
| Power Consumption | 4A at 120 VAC (typical) |
| Operating Humidity | 5% to 95% (non-condensing) |
| Input Voltage Range | 100-240VAC |
| Output 1 Regulation | +/- 2% |
| Output 2 Regulation | +/- 5% |
| Storage Temperature | -30°C to +70°C |
| Input Frequency Range | 47 – 63 HZ |
| Operating Temperature | -20°C to +70°C (restricted), -20°C to +50°C (unrestricted) |
| Output 1 Power Rating | 315W |
| Output 2 Power Rating | 30W |
| Output 1 Current Rating | 5.7A |
| Output 2 Current Rating | 1.25A |
Business account holders on Power Supplies typically save 12% vs. retail pricing. Create a free account to see your price.
It provides dual output: 315W at 56VDC and 30W at 24VDC, using terminal block connectors.
The input voltage range is 100-240VAC, with an input frequency range of 47 – 63 HZ.
Yes. Lantronix describes the form factor as compact Stand-Alone or DIN Rail.
The warranty is 5 Years.
