IOGEAR Quantum Thunderbolt 5 Dock Pro Docking Station

Name: IOGEAR Quantum Thunderbolt 5 Dock Pro Docking Station
Brand: IOGEAR
SKU: GTD58KTAA
Price: 349.95 USD
Availability: InStock

IOGEAR|

MPN: GTD58KTAA

UPC: 881317522054

In Stock

$349.95

Request for QuoteCall 224-955-1644 for Sales

Free 2-Day ShippingArrives by Monday, Oct 5

Authorized Dealer — Full manufacturer warranty

Save 25% with a Business Account

Exclusive pricing and Net-30 terms. Sign in or create a free account.

Create Free Business Account

Key Features

80 Gb/s Thunderbolt 5 host connection
Up to 140 W USB Power Delivery to the host
3 x Thunderbolt 5 downstream USB-C ports
Dual 8K at 60 Hz or triple 4K at 144 Hz display support
1 x 2.5 GbE RJ45 network port
4 x USB-A peripheral ports

Connect a Thunderbolt 5 Windows or macOS computer to one centralized desktop connection for displays, high-speed peripherals, wired networking, removable media, and audio. The IOGEAR GTD58KTAA uses an 80 Gb/s Thunderbolt 5 host connection and can provide up to 140 W of USB Power Delivery to the connected host. Its included 180 W AC adapter supplies power through a barrel connector. Three downstream Thunderbolt 5 USB-C ports extend the host connection to display-capable devices and additional Thunderbolt peripherals. One downstream port supports up to 60 W output, while two support up to 15 W Power Delivery. The dock supports dual displays at up to 8K resolution and 60 Hz, or three displays at up to 4K resolution and 144 Hz. This makes it suited to dense engineering, media, analytics, and multi-window desktop environments that need more display area than a notebook provides alone. Four USB-A ports support attached accessories, including three USB 3.1/3.2 Gen 2 ports and one USB 3.0/3.1/3.2 Gen 1 port. A 2.5 GbE RJ45 port provides a faster wired network connection than standard Gigabit Ethernet where the network supports it. The front-facing connectivity set also includes an SDXC card reader and a 3.5 mm headset jack for headphone, speaker, or microphone connections. Thunderbolt Share Software support adds a direct PC-to-PC connectivity option for compatible systems.

Ideal For

Thunderbolt 5 notebook desk with dual 8K monitors for detailed engineering or content work.
Three-display 4K workstation requiring high refresh rates for visual analysis and multi-window applications.
Shared office desk connecting USB accessories, SDXC media, wired 2.5 GbE, and a headset through one host cable.

Why This Product

1Combines an 80 Gb/s Thunderbolt 5 host link with up to 140 W host charging.
2Provides 3 downstream Thunderbolt 5 USB-C ports, including one with up to 60 W output.
3Supports both dual 8K at 60 Hz and triple 4K at 144 Hz display configurations.
4Adds 2.5 GbE, SDXC media access, 4 USB-A ports, and a 3.5 mm combo audio jack.

General

UPC	881317522054
Power Source	Included 180 W AC adapter, 20 VDC at 9 A
Product Name	Quantum Thunderbolt 5 Dock Pro
Dock Interface	Thunderbolt 5 USB-C host connection
Display Outputs	Video through 3 Thunderbolt 5 USB-C downstream ports
Shipping Weight	3.85 lb
Carton Dimensions	3.6 x 6.6 x 12.5 in
Platform Supported	Windows 10 to 11; macOS 14.4 to 15
Power Delivery (W)	Up to 140 W host power delivery
Maximum External Displays	Up to 3 external displays
Maximum Display Resolution	Dual 8K at 60 Hz or triple 4K at 144 Hz

Physical

Product Weight	1.59 lb
Product Dimensions	8.9 x 3.6 x 1.2 in

Connectivity

Ethernet Port	1 x 2.5 GbE RJ45
SD Card Reader	1 x SDXC card reader
Built-In USB Hub	Integrated USB hub
USB Type-A Ports	4 USB-A ports: 3 Gen 2 and 1 Gen 1
USB Type-C Ports	4 Thunderbolt 5 USB-C ports: 1 host and 3 downstream
Audio Jack (3.5mm)	1 x 3.5 mm headphone/microphone combo jack
Security Lock Slot	No security lock slot

Purchasing this for your business?

Business account holders on Docking Stations & USB Hubs typically save 25% vs. retail pricing. Create a free account to see your price.

Wholesale pricing below retail

Net-30 terms for qualified businesses

Volume discount tiers

Dedicated account representative

Saved payment methods & PO support

Priority order processing

Create Free Business Account

Frequently Asked Questions

What is the difference between Quantum Thunderbolt 5 Dock Pro and GTD58KTAA?▾

Quantum Thunderbolt 5 Dock Pro is the product model name, while GTD58KTAA is the ordering code for that IOGEAR configuration. Both names refer to the same Thunderbolt 5 docking station with display, USB, Ethernet, SDXC, and audio connectivity.

How many displays can the GTD58KTAA support?▾

The dock supports up to three external displays through its Thunderbolt 5 connectivity. Supported configurations include two displays at up to 7680 x 4320 and 60 Hz, or three displays at up to 3840 x 2160 and 144 Hz.

How much power can the Quantum Thunderbolt 5 Dock Pro provide to a host computer?▾

The Thunderbolt 5 host connection supports USB Power Delivery up to 140 W for the connected computer. The docking station uses an included 180 W AC adapter rated at 20 VDC and 9 A to supply its host charging and connected-port power.

What peripheral and network connections are available on this docking station?▾

Available connections include three downstream Thunderbolt 5 USB-C ports, four USB-A ports, one 2.5 GbE RJ45 port, one SDXC card reader, and one 3.5 mm headphone and microphone combo jack. This covers common desktop peripherals and wired network access.
