The RMCP7CG is a 4U spare front or rear panel for RMC Series rack mount aluminum instrument enclosures, in beige. It is intended for engineers and integrators who want a blank panel to machine for connectors, switches and displays, or who need to replace a damaged panel on an existing enclosure.
The RMCP7CG is the beige version; the part page lists the color as beige and the drawing calls it painted off white smooth. It is useful for a two-tone look or for matching lighter equipment, and shares its dimensions with the textured black RMCP7 and smooth black RMCP7BK.
The panel is aluminum and, per the part drawing, measures 6.98 in (177 mm) high by 16.72 in (425 mm) wide by .06 in (2 mm) thick; the series lists front and rear panels as 0.064" (1.6 mm) thick. It has a mounting height of 7 in, or 4U, and four countersunk mounting holes, Ø .16 in with a Ø .25 in x 82° countersink.
Replacement front and rear panels come in the full 17 in width only, so this panel suits the 17.00 in (432 mm) wide 4U enclosures: RMCS190713BK1/RMCV190713BK1. The RMC assembly instructions fasten front and rear panels with #6-32 x 3/8" flat head screws, with a recommended screw torque of 8.9-9.4 lbf-in (100-110 cN-m). The series notes that panels are not grounded to the frame because of the finish, so the grounding method is up to the user.
The RMCP7CG ships in a box and is RoHS and REACH compliant. The listed shipping weight is 0.82 lbs (0.37 kg).
| Series | RMC Series Rack Mount Aluminum Instrument Enclosure |
| Description | Rack - spare panel for RMC series, 4U, Beige |
| Product Type | Front Panel (front / rear replacement panel) |
| Short Description | 7" SPARE FRONT PANEL |
| Other Finishes, Same Size | RMCP7, RMCP7BK |
| Panel Width | 16.72 in (425 mm) |
| Panel Height | 6.98 in (177 mm) |
| Panel Thickness (Drawing) | .06 in (2 mm) |
| Front/Rear Panel Thickness (Series) | 0.064" (1.6 mm) |
| UPC | 623980419909 |
| UNSPSC | 43201602 |
| Rack Units | 4U |
| Mounting Height | 7 in |
| Recommended Screw Torque | 8.9-9.4 lbf-in (100-110 cN-m) |
| Compatible Enclosure Width | Full 17" width only |
| Compatible Enclosures (Solid/Vented) | RMCS190713BK1/RMCV190713BK1 |
| Panel Fasteners (Per Assembly Instructions) | #6-32 x 3/8" flat head screw through front and rear panels |
| Packaging Type | Box |
| Shipping Weight | 0.82 lbs (0.37 kg) |
| Color | Beige |
| Finish | Beige (Painted off white smooth) |
| Material | Aluminum |
| Grounding | Panels are not grounded to frame due to powder coat finish; grounding method to be determined by user |
| RoHS Compliant | Yes |
| REACH Compliant | Yes |
Business account holders get access to exclusive pricing, volume discounts, and dedicated support. Create a free account to get started.
It is a 4U panel in the full 17" width, for RMCS190713BK1 (solid) and RMCV190713BK1 (vented). It does not suit the 8.50 in wide RMC enclosures, since replacement panels are full 17" width only.
Yes. It is listed as a front / rear panel (7" SPARE FRONT PANEL).
Beige; the drawing calls it painted off white smooth. The same size is also offered as RMCP7 and RMCP7BK.
The drawing shows 6.98 in (177 mm) high, 16.72 in (425 mm) wide and .06 in (2 mm) thick, for a 7 in (4U) mounting height.
The assembly instructions use #6-32 x 3/8" flat head screws through the front and rear panels at 8.9-9.4 lbf-in (100-110 cN-m). Panels are not grounded to the frame due to the finish, so the user determines the grounding method.
