Linear EN-EXN Door Access Control System, 2-Door, Fast Ethernet

Add controlled access where a single panel is not enough. The Linear EN-EXN expands an EN system to manage two doors from one standalone controller, making it a practical fit for poolhouses, community buildings, and other secondary structures on the same property. With support for up to 20,000 users, it scales cleanly for larger credential populations without adding unnecessary complexity. The controller includes four Form C relays rated at 3 A @ 24 V, two door switch monitor inputs, two request-to-exit inputs, two auxiliary inputs, and two Wiegand inputs. One Wiegand input also supports PBUS accessories, giving installers flexibility when integrating readers and peripherals. Fast Ethernet, serial, and network (RJ-45) connectivity help it fit into existing infrastructure, while proximity and key code identification methods support common access workflows. For installations that need dependable supervision, the EN-EXN can record power outages in the event log when paired with the optional Power Distribution Module. The metal housing, keyed lock, and knockout provisions support cleaner field installation and a more secure finish. It is a purpose-built control point for teams that need more than basic door release: they need traceable events, flexible wiring, and a platform that can grow with the site.
